CM599LH-W - 3kW Low Chirp / 1kW High Chirp Depth/Temperature Transducer. Dual 9pin connector and 10m (33ft) cable. NSSevo3S or S5100 Sonar module required.
Get more coverage under your boat with Airmar’s unique wide-beam, high-frequency, Chirp-ready transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band results in superior resolution. The constantly wide beam provides twice the coverage and excellent fish arches on the display compared to most high-frequency, narrow-beam transducer options.
The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat is essential down to 152 m (500').
The low-frequency band is rated to 3 kW and produces amazing deep-water performance to 3,048 m (10,000'). Get the best of both worlds with Airmar’s dual-frequency, Chirp-ready transducer with wide-beam coverage.
Features
- Depth and fast-response water-temperature sensor
- 3 kW for superior deep-water performance
- 3 kW low frequency: 28 to 60 kHz
- 23° to 9° port-starboard beamwidth
- 11° to 5° fore-aft beamwidth
- Maximum depth performance to 3,048 m (10,000')
- 1 kW high frequency: 150 to 250 kHz
- 25° constant beamwidth
- Maximum depth of 152 m (500')
- 132 kHz of total bandwidth from one transducer
- Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
- High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
- High wide beamwidth yields more coverage for detecting fish in the upper-water column
- Urethane housing with Curved-edge Design for wet-box installation
- Also available as an external (R509LHW) mount
Specifications
Weight | 14.2 kg (31.2 lb.) |
Recommended Boat Length | 8 m (25') and above |
Hull Material | Solid fiberglass or steel |
Hull Deadrise | Accommodates any deadrise angle based on custom-cavity or welded-tank construction |
Acoustic Window | Urethane |
Transducer Element | 25 internal broadband ceramic assemblies |
SKU | 000-13941-001 |
---|---|
Barcode # | 9420024163313 |
Brand | Airmar |
Shipping Weight | 12.9000kg |
Shipping Width | 0.406m |
Shipping Height | 0.263m |
Shipping Length | 0.305m |
