B45 - Bronze 600W Through-Hull 50/200 kHz Depth and Temperature transducer. Black 9 pin connector with 10m cable. (33ft)
The B45 is our smallest and most economical, dual-frequency, bronze, stem transducer. The included fairing streamlines the transducer and increases the performance—even at higher speeds.
Features
- Depth and fast-response water-temperature sensor
- 600 W Dual-frequency element
- 50 kHz with a wide 45° beamwidth for depth performance to 353 m (1,200')
- 200 kHz with a 12° beamwidth for depth performance to 206 m (700')
- Excellent performance and sensitivity in a small housing
- Bronze-stem housing with high-performance fairing for optimal performance at speed
- Bronze transducer housing
Specifications
- Weight: 2.5 kg (5.5 lb.)
- Recommended Boat Length: Up to 9 m (30’)
- Hull Material: Fiberglass or wood
- Hull Deadrise: Up to 26° with fairing
- Acoustic Window: Urethane
- Hole Diameter: 22 mm or 7/8"
- Includes: High-performance fairing and mounting hardware
SKU | 000-13946-001 |
---|---|
Barcode # | 9420024163368 |
Brand | Airmar |
Shipping Weight | 1.6000kg |
Shipping Width | 0.254m |
Shipping Height | 0.095m |
Shipping Length | 0.200m |
