Selected Part Number: PACSWICP5
General Product Information

Steering Wheel Control Interface


Retain your factory audio steering wheel controls and rear seat controls with one of the most advanced steering wheel interfaces available from PAC.

Works With Analog Vehicles

Based on the reliability of PAC long line of steering wheel retention interfaces, the SWI-CP5 allows easy retention of your steering wheel mounted audio control buttons in vehicles featuring analogue (resistive) wiring styles.


With added ability to program each button for two functions, you can now double your steering wheel controls with ease!

Ready For Todays Data Vehicles

If your vehicle features more complex data network, there’s a good chance your audio mounted steering wheel buttons are data based. With its data network compatibility, the SWI-CP5 allows easy retention of audio steering wheel buttons for your aftermarket radio.


Compatible vehicle networks including:

  • GMLAN
  • CLASS II
  • LIN-BUS
  • Serial Data
  • I-BUS
  • CAN BUS

(Check vehicle application listing for compatibility information)

Programming Is Easy as 1,2,3

Programming is made easy with select vehicle profiles preloaded which can be easily setup using the DIP switch settings found on the module.


Simply set the switches and plug the module in to the supplied harness (requires to be hardwired into the vehicle or can be used with select plug and play harnesses avail separately in packages) and away you go.


No preset available? Want to customize your steering wheel button features?

No worries!

You can easily manually map your vehicles buttons into the vehicle and customise the button features* (dependant on the aftermarket radios remote control features. See Installation manual for total list of features)


Are you regularly programming the same kind of vehicles? want to backup and save your configuration for easy firmware updating in the future?

With the PAC SWI-CP5's Android and iOS application, you can easily configure and program your steering wheel buttons straight from your mobile or tablet device

(required USB Lead, not included)

Major Brands Supported

Designed to work with a wide range of vehicles,

the PAC SWI-CP5 is compatible with the following brands of aftermarket radios including

  • Alpine
  • Clarion
  • Fusion
  • JVC
  • Kenwood
  • Lightning Audio
  • Nakamichi
  • Pioneer
  • Sony
  • Stinger

and more!

Feature Packed

Speed through your radio replacement installation when using the SWI-RC-1 to retain your factory steering wheel controls.

  • Configure using the Web Application, Android Application, Apple Application, USB flash drive or manual programming.
  • Compatible in vehicles equipped with LAN, LIN, CAN, Class II, Analog or Serial Data SWC.
  • Create and save custom vehicle configuration files for later use.
  • Ability to assign two radio functions to one SWC button.
  • Audible feedback for programming confirmation.
  • Highly visible tricolor LED to keep the user informed of the modules status.
  • Retains memory even if power is lost.
  • Equipped with a manual learning function for compatibility with unlisted analog vehicles.

What Do You Get?

The PAC ControlPRO 5 SWI-CP5 includes

  • Vehicle Interface
  • Universal Bare Wire Harness
  • Instruction Manual
  • USB OTG Lead


Compatibility Notes

  • CAN-BUS vehicles cannot be manually programmed.
  • ACC 12v output only available on CAN vehicles where IGN data is available
  • Buttons can only be remapped to what is available selected brand of aftermarket radio
  • FORD, EXPLORER 2002-2005 — Models with 24 Pin Connector
  • FORD, FIESTA 2002-2006 Models with 3 section headunit
  • FORD, FIESTA 2009-2016 — Models with monochrome screen (Clock & Trip screen access is lost)
  • FORD, FOCUS (Incl XR5) 1999-2004 — Models with 17 Pin Connector
  • FORD, FOCUS (Incl XR5) 2005-2008 — Models with 24 Pin Connector
  • HOLDEN, BARINA 2012-2016 — Non MyLink Models (Will lose access to vehicle settings)
  • HOLDEN, BARINA SPARK 2010-2016 — 2010-2012 Models with 44 Pin Connector
  • HOLDEN, CAPTIVA 7 2006-2015 — Nav Models will lose screen
  • HOLDEN, COLORADO (Incl 7) 2012-2013 — Models with 16 Pin Connector
  • HOLDEN, COLORADO (Incl 7) 2014-2016 — Models with 16 Pin Connector
  • HOLDEN, VIVA, 2006-2011 — Models with 18 Pin Connector
  • HONDA, ACCORD EURO 2008-2015 — Models with 24 Pin Connector
  • HONDA, CITY, 2015-2018 — Models with mechless head unit
  • HONDA, CIVIC HATCH, 2006-2011 — Will not retain OE display above head unit
  • HONDA, CIVIC HATCH, 2012-2015 — Nav models – Unable to adjust clock on HUD
  • HONDA, CRV, 2007-2011 — Models with 20 Pin Connector
  • HONDA, CRV, 2012-2015 — Nav models – Unable to adjust clock on HUD
  • HONDA, HRV, 2015-2017 — Models with mechless head unit
  • HONDA, HRV, 2017-2018 —Models with mechless head unit
  • HONDA, JAZZ, 2008-2013 — Models with 24 Pin Connector
  • HONDA, JAZZ, 2014-2016 — Models with mechless head unit
  • HONDA, JAZZ, 2017-2018 — Models with mechless head unit with 24 Pin Connector
  • HONDA, MDX, 2001-2006 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2005-2009 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2009-2013 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2014-2016 — Unable to adjust clock in cluster
  • HYUNDAI, ACCENT, 2006-2008 — Models with 24 Pin Connector
  • HYUNDAI, ACCENT, 2011-2018 — Models with 24 Pin Connector
  • HYUNDAI, ELANTRA, 2007-2010 — Models with 24 Pin Connector
  • HYUNDAI, ELANTRA, 2011-2013 — Models with 24 Pin Connector
  • HYUNDAI, GRANDEUR, 2006-2010 — Models with 24 Pin Connector
  • HYUNDAI, i30, 2012- 2016 — Nav Models with 24 Pin Connector
  • HYUNDAI, ILOAD (Incl IMAX), 2016-2018 — Models with 38 Pin Connector
  • HYUNDAI, SONATA, 2006-2008 — Models with 24 Pin Connector
  • IVECO, DAILY, 2015-2017 — Models with 12 Pin Connector
  • KIA, CARNIVAL (Incl Grand), 2006-2015 — Models with mini ISO Connector
  • KIA, CERATO, 2010-2013 — Models with mini ISO Connector
  • KIA, SORENTO, 2009-2012 — Non Amplified Models
  • LAND ROVER, DISCOVERY III, 2005-2010 — Non Amplified Models
  • LAND ROVER, FREELANDER II, 2007-2011 — Non Amplified Models
  • LAND ROVER, RANGE ROVER, 2005-2010 — Non Amplified Models
  • LAND ROVER, RANGE ROVER 2011-2014 — Non Amplified Models
  • LEXUS, IS, 1999-2005 — Non Navigation Models
  • MAZDA, 3, 2009-2013 — Non Amplified Models (Will not retain clock & trip display)
  • MAZDA, 6, 2010-2012 — Non Amplified Models (Will not retain clock & trip display)
  • MAZDA, MX5, 1998-2005 — Non Amplified Models
  • MAZDA, MX5, 2006-2008 — Non Amplified Models
  • MAZDA, MX5, 2009-2013 — Non Amplified Models
  • MAZDA, TRIBUTE, 2001-2005 — Models with 14 Pin Connector
  • MITSUBISHI, ASX, 2013-2018 — Amplified Models (AXTO-MI2 also required)
  • MITSUBISHI, LANCER (Inc Evolution), 2014-2018 — Amplified Models (AXTO-MI2 also required)
  • MITSUBISHI, MAGNA (Inc Verada), 1997-2005 — Models with 6 Pin Connector
  • MITSUBISHI, OUTLANDER, 2013-2018 — Amplified Models (AXTO-MI3 also required)
  • MITSUBISHI, PAJERO SPORT, 2015-2018 — Amplified Models (AXTO-MI3 also required)MITSUBISHI, TRITON, 2007-2013 — Models with trip display
  • MITSUBISHI, TRITON, 2013-2015 — Models with trip display
  • NISSAN, 350Z, 2006-2008 — Models with 32 Pin Connector
  • NISSAN, MAXIMA, 1995-2003 — Models with 32 Pin Connector
  • NISSAN, PATHFINDER, 2005-2013 — Models with 16A Connector
  • NISSAN, SKYLINE, 2001-2004 — Models with 16 Pin Connector
  • PORSCHE 911 2005 – 2012 (997) — 2005 – 2009 Models Only
  • SUZUKI, GRAND VITARA, 2005-2014 — 2011+ Models
  • SUZUKI, SWIFT, 2011-2016 — 2011+ Models
  • TOYOTA, CAMRY, 2018-2018 — Models with 28 Pin Connectors

Product Overview Video


Important Product Compatibility Information
Retain Factory Steering Wheel Audio Controls?

YES – Will retain Steering Wheel Audio Controls with Select Aftermarket Radios

Plug & Play

NO

Retain Parking Sensors?

NO – If vehicle OEM radio was generating the parking sensor tones. If parking sensors are not part of the factory radio, they should not be effected

Retain Factory Amplifier?

NO

Retain vehicle OE clock & trip display?

NO – If OEM Radio Controlled This Feature

Vehicle Notes

FORD, EXPLORER 2002-2005 — Models with 24 Pin Connector
FORD, FIESTA 2002-2006 Models with 3 section headunit
FORD, FIESTA 2009-2016 — Models with monochrome screen (Clock & Trip screen access is lost)
FORD, FOCUS (Incl XR5) 1999-2004 — Models with 17 Pin Connector
FORD, FOCUS (Incl XR5) 2005-2008 — Models with 24 Pin Connector
HOLDEN, BARINA 2012-2016 — Non MyLink Models (Will lose access to vehicle settings)
HOLDEN, BARINA SPARK 2010-2016 — 2010-2012 Models with 44 Pin Connector
HOLDEN, CAPTIVA 7 2006-2015 — Nav Models will lose screen
HOLDEN, COLORADO (Incl 7) 2012-2013 — Models with 16 Pin Connector
HOLDEN, COLORADO (Incl 7) 2014-2016 — Models with 16 Pin Connector
HOLDEN, VIVA, 2006-2011 — Models with 18 Pin Connector
HONDA, ACCORD EURO 2008-2015 — Models with 24 Pin Connector
HONDA, CITY, 2015-2018 — Models with mechless head unit
HONDA, CIVIC HATCH, 2006-2011 — Will not retain OE display above head unit
HONDA, CIVIC HATCH, 2012-2015 — Nav models – Unable to adjust clock on HUD
HONDA, CRV, 2007-2011 — Models with 20 Pin Connector
HONDA, CRV, 2012-2015 — Nav models – Unable to adjust clock on HUD
HONDA, HRV, 2015-2017 — Models with mechless head unit
HONDA, HRV, 2017-2018 —Models with mechless head unit
HONDA, JAZZ, 2008-2013 — Models with 24 Pin Connector
HONDA, JAZZ, 2014-2016 — Models with mechless head unit
HONDA, JAZZ, 2017-2018 — Models with mechless head unit with 24 Pin Connector
HONDA, MDX, 2001-2006 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2005-2009 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2009-2013 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2014-2016 — Unable to adjust clock in cluster
HYUNDAI, ACCENT, 2006-2008 — Models with 24 Pin Connector
HYUNDAI, ACCENT, 2011-2018 — Models with 24 Pin Connector
HYUNDAI, ELANTRA, 2007-2010 — Models with 24 Pin Connector
HYUNDAI, ELANTRA, 2011-2013 — Models with 24 Pin Connector
HYUNDAI, GRANDEUR, 2006-2010 — Models with 24 Pin Connector
HYUNDAI, i30, 2012- 2016 — Nav Models with 24 Pin Connector
HYUNDAI, ILOAD (Incl IMAX), 2016-2018 — Models with 38 Pin Connector
HYUNDAI, SONATA, 2006-2008 — Models with 24 Pin Connector
IVECO, DAILY, 2015-2017 — Models with 12 Pin Connector
KIA, CARNIVAL (Incl Grand), 2006-2015 — Models with mini ISO Connector
KIA, CERATO, 2010-2013 — Models with mini ISO Connector
KIA, SORENTO, 2009-2012 — Non Amplified Models
LAND ROVER, DISCOVERY III, 2005-2010 — Non Amplified Models
LAND ROVER, FREELANDER II, 2007-2011 — Non Amplified Models
LAND ROVER, RANGE ROVER, 2005-2010 — Non Amplified Models
LAND ROVER, RANGE ROVER 2011-2014 — Non Amplified Models
LEXUS, IS, 1999-2005 — Non Navigation Models
MAZDA, 3, 2009-2013 — Non Amplified Models (Will not retain clock & trip display)
MAZDA, 6, 2010-2012 — Non Amplified Models (Will not retain clock & trip display)
MAZDA, MX5, 1998-2005 — Non Amplified Models
MAZDA, MX5, 2006-2008 — Non Amplified Models
MAZDA, MX5, 2009-2013 — Non Amplified Models
MAZDA, TRIBUTE, 2001-2005 — Models with 14 Pin Connector
MITSUBISHI, ASX, 2013-2018 — Amplified Models (AXTO-MI2 also required)
MITSUBISHI, LANCER (Inc Evolution), 2014-2018 — Amplified Models (AXTO-MI2 also required)
MITSUBISHI, MAGNA (Inc Verada), 1997-2005 — Models with 6 Pin Connector
MITSUBISHI, OUTLANDER, 2013-2018 — Amplified Models (AXTO-MI3 also required)
MITSUBISHI, PAJERO SPORT, 2015-2018 — Amplified Models (AXTO-MI3 also required)MITSUBISHI, TRITON, 2007-2013 — Models with trip display
MITSUBISHI, TRITON, 2013-2015 — Models with trip display
NISSAN, 350Z, 2006-2008 — Models with 32 Pin Connector
NISSAN, MAXIMA, 1995-2003 — Models with 32 Pin Connector
NISSAN, PATHFINDER, 2005-2013 — Models with 16A Connector
NISSAN, SKYLINE, 2001-2004 — Models with 16 Pin Connector
PORSCHE 911 2005 – 2012 (997) — 2005 – 2009 Models Only
SUZUKI, GRAND VITARA, 2005-2014 — 2011+ Models
SUZUKI, SWIFT, 2011-2016 — 2011+ Models
TOYOTA, CAMRY, 2018-2018 — Models with 28 Pin Connectors

Product Vehicle Applications
What Fits My Car

This product is compatbile with the following vehicles. If no vehicles are listed, this product is universal product (non vehicle specific)
Vehicle Make Vehicle Model Vehicle Year + Vehicle Chassis Code
AUDI A4 (Incl S4) 2001 - 2008 (B6-B7)
BMW 3 SERIES (Incl M3) 1997 - 2005 (E46)
BMW 5 SERIES (Incl M5) 1996 - 2003 (E39)
BMW 5 SERIES (Incl M5) 2004 - 2011 (E60)
BMW 7 SERIES 1994 - 2001 (E38)
BMW X5 2000 - 2005 (E53)
BMW X5 2006 - 2011 (E70)
BMW Z3 1996 - 2002 (E36-E37-E38)
BMW Z4 2003 - 2008 (E85-E86)
CADILLAC ESCALADE 1999 - 2001 (FIRST GEN)
CADILLAC ESCALADE 2002 - 2006 (SECOND GEN)
CHEVROLET AVALANCHE 1999 - 2002 (FIRST GEN)
CHEVROLET AVALANCHE 2003 - 2006 (SECOND GEN)
CHEVROLET AVALANCHE 2007 - 2011 (THIRD GEN)
CHEVROLET CAMARO 1990 - 1992 (3RD GEN)
CHEVROLET CAMARO 1993 - 2002 (4TH GEN)
CHEVROLET CORVETTE 1984 - 1989 (C4)
CHEVROLET CORVETTE 1990 - 1996 (C4)
CHEVROLET CORVETTE 1997 - 2004 (C5)
CHEVROLET CORVETTE 2005 - 2013 (C6)
CHEVROLET SSR 2003 - 2006 (Super Sports Roadster)
CHEVROLET SUBURBAN 2000 - 2006 (NINTH GEN)
CHRYSLER NEON 1996 - 1999 (FIRST GEN)
CHRYSLER NEON 2000 - 2006 (SECOND GEN)
CHRYSLER PROWLER 2002 - 2002 (GRRRR…)
CHRYSLER PT CRUISER 2001 - 2005 (FIRST GEN)
CHRYSLER PT CRUISER 2006 - 2011 (SECOND GEN)
CHRYSLER VOYAGER (Incl GRAND VOYAGER) 1996 - 2001 (3RD GEN)
CHRYSLER VOYAGER (Incl GRAND VOYAGER) 2001 - 2007 (4TH GEN)
CITROEN DS3 2009 - 2016 (FIRST GEN)
DODGE CALIBER 2006 - 2009 (FIRST GEN)
DODGE RAM 2002 - 2005 (3RD GEN)
FIAT DUCATO 2015 - 2018 (FOURTH GEN)
FORD COUGAR 1999 - 2000 (MK1)
FORD ESCAPE 2001 - 2007 (FIRST GEN)
FORD ESCAPE 2006 - 2011 (2ND GEN)
FORD EXPLORER 1995 - 2001 (UN - US)
FORD EXPLORER 2002 - 2005 (UT - UX)
FORD EXPLORER 2006 - 2011 (UZ)
FORD F SERIES 1995 - 2004 (10th Gen)
FORD F SERIES 2005 - 2008 (11th Gen)
FORD FALCON 1998 - 2002 (AU)
FORD FALCON 2003 - 2008 (BA-BF)
FORD FALCON 2009 - 2011 (FG)
FORD FIESTA 2009 - 2016 (WS-WT-WZ)
FORD FOCUS (Incl XR5) 2005 - 2007 (LS-LT)
FOTON TUNLAND 2012 - 2016 (E3)
GREAT WALL STEED 2016 - 2018 (NBP)
GREAT WALL V200 + V240 2009 - 2014 (K2)
GREAT WALL X240 2010 - 2011 (H5)
HARLEY DAVIDSON STREET GLIDE 1998 - 2013 (MOTORBIKE)
HARLEY DAVIDSON ULTRA GLIDE 1998 - 2013 (MOTORBIKE)
HOLDEN BARINA 2006 - 2011 (TK)
HOLDEN BARINA 2012 - 2016 (TM)
HOLDEN BARINA SPARK 2010 - 2016 (MJ)
HOLDEN CAPTIVA 7 (Incl Variants) 2006 - 2015 (CG)
HOLDEN COLORADO (Incl 7) 2012 - 2013 (RG)
HOLDEN COLORADO (Incl 7) 2014 - 2016 (RG)
HOLDEN COMMODORE 1997 - 2002 (VT-VX)
HOLDEN COMMODORE 2002 - 2007 (VY-VZ)
HOLDEN EPICA 2006 - 2011 (EP)
HOLDEN EQUINOX 2017 - 2018 (EQ)
HOLDEN TIGRA 2004 - 2009 (XC)
HOLDEN VECTRA 2003 - 2011 (ZC)
HOLDEN VIVA 2006 - 2011 (JF)
HONDA ACCORD 1989 - 1993 (4TH GEN)
HONDA ACCORD 1993 - 1997 (5TH GEN)
HONDA ACCORD 2003 - 2007 (7TH GEN)
HONDA ACCORD 2008 - 2012 (8TH GEN)
HONDA ACCORD EURO 2003 - 2007 (7TH GEN)
HONDA ACCORD EURO 2008 - 2015 (8TH GEN)
HONDA CITY 2009 - 2013 (GM)
HONDA CITY 2013 - 2015 (GM)
HONDA CITY 2015 - 2019 (GM)
HONDA CIVIC HATCH 2001 - 2005 (7TH GEN)
HONDA CIVIC HATCH 2006 - 2011 (8TH GEN)
HONDA CIVIC HATCH 2012 - 2015 (9TH GEN)
HONDA CIVIC HATCH 2015 - 2016 (9TH GEN)
HONDA CIVIC SEDAN 2001 - 2005 (7TH GEN)
HONDA CIVIC SEDAN 2006 - 2011 (8TH GEN)
HONDA CIVIC SEDAN 2012 - 2015 (9TH GEN)
HONDA CRV 1997 - 2006 (RD)
HONDA CRV 2007 - 2011 (RE)
HONDA CRV 2012 - 2015 (RM)
HONDA CRZ 2010 - 2014 (ZF)
HONDA HRV 2015 - 2017 (2ND GEN)
HONDA HRV 2017 - 2019 (2ND GEN)
HONDA INSIGHT 2009 - 2013 (ZE)
HONDA INTEGRA 1993 - 2001 (DB - DC1 - DC2)
HONDA INTEGRA 2002 - 2006 (DC5)
HONDA JAZZ 2001 - 2007 (GD)
HONDA JAZZ 2008 - 2013 (GE)
HONDA JAZZ 2014 - 2016 (GF)
HONDA JAZZ 2017 - 2019 (GF)
HONDA LEGEND 1990 - 1996 (KA7-KA8)
HONDA LEGEND 1996 - 2003 (KA9)
HONDA MDX 2001 - 2006 (YD1)
HONDA ODYSSEY 1995 - 1999 (1ST GEN (RA1 - RA5))
HONDA ODYSSEY 2004 - 2009 (3RD GEN (RB1 - RB2))
HONDA ODYSSEY 2009 - 2013 (4TH GEN (RB3 - RB4))
HONDA ODYSSEY 2014 - 2018 (5TH GEN (RC1 - RC2))
HONDA PRELUDE 1991 - 1996 (4TH GEN (BA - BB))
HONDA PRELUDE 1997 - 2001 (5TH GEN (BB5-BB9))
HONDA S2000 1999 - 2011 (AP1 - AP2)
HUMMER H2 2002 - 2007 (H2)
HUMMER H2 2008 - 2011 (H2)
HYUNDAI ACCENT 2006 - 2008 (MC)
HYUNDAI ACCENT 2011 - 2019 (RB)
HYUNDAI ELANTRA 2007 - 2010 (HD)
HYUNDAI ELANTRA 2011 - 2013 (MD-MD2)
HYUNDAI ELANTRA 2014 - 2015 (MD3)
HYUNDAI ELANTRA 2016 - 2018 (AD)
HYUNDAI GETZ 2002 - 2010 (TB)
HYUNDAI GRANDEUR 2006 - 2010 (TG)
HYUNDAI i20 2010 - 2012 (PB)
HYUNDAI i20 2012 - 2015 (PB)
HYUNDAI i30 2007 - 2011 (FD)
HYUNDAI i30 2012 - 2016 (GD-GD2)
HYUNDAI i40 2012 - 2018 (VF-VF2-VF3)
HYUNDAI i45 2010 - 2012 (YF)
HYUNDAI ILOAD (Incl IMAX) 2008 - 2016 (TQ)
HYUNDAI ILOAD (Incl IMAX) 2016 - 2018 (TQ3-V Series II)
HYUNDAI ILOAD (Incl IMAX) 2018 - 2019 (TQ4)
HYUNDAI ix35 2010 - 2013 (LM)
HYUNDAI ix35 2014 - 2015 (LM) - WITH NAV
HYUNDAI ix35 2014 - 2015 (LM) - WITHOUT NAV
HYUNDAI SANTA FE 2001 - 2006 (SM)
HYUNDAI SANTA FE 2009 - 2012 (CM)
HYUNDAI SANTA FE 2012 - 2018 (DM)
HYUNDAI SONATA 1995 - 2001 (Y3)
HYUNDAI SONATA 2002 - 2005 (EF)
HYUNDAI SONATA 2006 - 2008 (NF)
HYUNDAI SONATA 2009 - 2011 (YF)
HYUNDAI TIBURON 1997 - 2002 (RD - RD2)
HYUNDAI TIBURON 2003 - 2008 (GK)
HYUNDAI TUCSON 2015 - 2018 (TL)
HYUNDAI VELOSTER 2012 - 2017 (1ST GEN)
ISUZU DMAX 2012 - 2016 (RT50 - RT85)
ISUZU DMAX 2016 - 2019 (RT50 - RT85)
ISUZU MUX 2013 - 2015 (RF10)
ISUZU MUX 2016 - 2017 (RF20)
IVECO DAILY 2007 - 2014 (5TH GEN)
IVECO DAILY 2015 - 2017 (6TH GEN)
IVECO DAILY 2018 - 2019 (6TH GEN)
JAGUAR S-TYPE 2000 - 2002 (No Chassis Code)
JAGUAR S-TYPE 2003 - 2008 (No Chassis Code)
JAGUAR X-TYPE 2002 - 2015 (No Chassis Code)
JEEP CHEROKEE 1994 - 2001 (XJ)
JEEP CHEROKEE 2001 - 2007 (KJ)
JEEP COMMANDER 2005 - 2008 (XK)
JEEP COMPASS 2007 - 2009 (MK)
JEEP GRAND CHEROKEE 1999 - 2004 (WJ-WG)
JEEP GRAND CHEROKEE 2005 - 2007 (WH-WK)
JEEP PATRIOT 2007 - 2009 (MK)
JEEP WRANGLER 1986 - 2004 (YJ - TJ)
JEEP WRANGLER 2003 - 2006 (TJ)
KIA CARNIVAL (Incl Grand) 1998 - 2005 (KV-II)
KIA CARNIVAL (Incl Grand) 2006 - 2015 (VQ)
KIA CERATO 2010 - 2012 (TD)
KIA CERATO 2013 - 2018 (YD)
KIA CERATO 2019 - 2021 (BD)
KIA MAGENTIS 2006 - 2010 (MG)
KIA OPTIMA 2006 - 2010 (MG)
KIA OPTIMA 2010 - 2013 (TF1)
KIA OPTIMA 2013 - 2015 (TF2)
KIA PICANTO 2016 - 2017 (TA)
KIA PRO CEED 2014 - 2015 (JD)
KIA RIO 2010 - 2014 (UB)
KIA RIO 2014 - 2017 (UB)
KIA RONDO 2007 - 2012 (UN)
KIA RONDO 2013 - 2018 (RP)
KIA SORENTO 2007 - 2008 (BL)
KIA SORENTO 2009 - 2012 (XM)
KIA SORENTO 2013 - 2015 (XM)
KIA SORENTO EX 2003 - 2009 (BL)
KIA SORENTO LX 2001 - 2003 (BL)
KIA SORENTO LX 2007 - 2009 (BL)
KIA SOUL 2009 - 2011 (AM)
KIA SOUL 2014 - 2018 (PS)
KIA SPORTAGE 2010 - 2015 (SL)
KIA SPORTAGE 2016 - 2018 (QL)
LAMBORGHINI GALLARDO 2005 - 2011 (No Chassis Code)
LAND ROVER DISCOVERY III 2005 - 2010 (L319)
LAND ROVER RANGE ROVER (Incl HSE - VOGUE) 2002 - 2012 (L322)
LEXUS ES 1992 - 1996 (XV10)
LEXUS ES 1997 - 2001 (XV20)
LEXUS ES 2002 - 2006 (XV30)
LEXUS GS 1998 - 2006 (S160)
LEXUS IS 1999 - 2005 (XE10)
LEXUS LX 1998 - 2007 (J100)
LEXUS RX 2003 - 2008 (XU30)
MAZDA 2 2007 - 2015 (DE)
MAZDA 3 2004 - 2009 (BK)
MAZDA 3 2009 - 2013 (BL)
MAZDA 3 2013 - 2016 (BM) - WITH MONOCHROME DISPLAY
MAZDA 323 1986 - 1994 (BF - BG)
MAZDA 6 2003 - 2005 (GG)
MAZDA 6 2005 - 2008 (GG)
MAZDA 6 2010 - 2012 (GH)
MAZDA BT-50 2015 - 2019 (UR) WITH 7inch NAV
MAZDA CX5 2015 - 2017 (KE)
MAZDA CX7 2006 - 2010 (ER)
MAZDA CX7 2010 - 2011 (ER)
MAZDA MPV 2000 - 2006 (LW)
MAZDA MX5 1998 - 2005 (NB)
MAZDA MX5 2006 - 2008 (NC)
MAZDA MX5 2009 - 2013 (ND)
MAZDA PREMACY 2000 - 2006 (1ST GEN)
MAZDA RX8 2004 - 2008 (FE)
MAZDA RX8 2008 - 2012 (FE)
MAZDA TRIBUTE 2001 - 2006 (1ST GEN)
MAZDA TRIBUTE 2006 - 2011 (2ND GEN)
MERCEDES A CLASS 2005 - 2007 (W169)
MERCEDES B CLASS 2005 - 2007 (W245)
MERCEDES B CLASS 2007 - 2011 (W245)
MERCEDES C CLASS 2000 - 2004 (W203)
MERCEDES C CLASS 2005 - 2008 (W203)
MERCEDES CLK 2002 - 2004 (W208)
MERCEDES CLK 2005 - 2011 (W209)
MERCEDES CLS 2005 - 2010 (W219)
MERCEDES E CLASS 2002 - 2007 (W211)
MERCEDES G CLASS 2006 - 2012 (W463)
MERCEDES GL CLASS 2006 - 2012 (X164)
MERCEDES M CLASS 1999 - 2004 (W163)
MERCEDES M CLASS 2005 - 2011 (W164)
MERCEDES R CLASS 2006 - 2012 (W251)
MERCEDES S CLASS 1998 - 2006 (W220)
MERCEDES SL CLASS 2005 - 2013 (R230)
MERCEDES SLK CLASS 2004 - 2011 (R171)
MERCEDES SPRINTER 2007 - 2018 (W906)
MERCEDES VITO (Inc VIANO or VALENTE) 2004 - 2007 (W639)
MERCEDES VITO (Inc VIANO or VALENTE) 2007 - 2015 (W639)
MITSUBISHI 380 2004 - 2011 (DB)
MITSUBISHI ASX 2010 - 2013 (XA)
MITSUBISHI ASX 2013 - 2019 (XB - XC)
MITSUBISHI CHALLENGER 2009 - 2013 (PB)
MITSUBISHI CHALLENGER 2013 - 2015 (PC)
MITSUBISHI DELICA 2007 - 2010 (5TH GEN)
MITSUBISHI LANCER (Inc Evolution) 2007 - 2013 (CJ)
MITSUBISHI LANCER (Inc Evolution) 2014 - 2018 (CF)
MITSUBISHI MAGNA (Inc Verada) 1997 - 2005 (TF)
MITSUBISHI MIRAGE 2013 - 2019 (LA)
MITSUBISHI OUTLANDER 2003 - 2006 (ZE-ZF)
MITSUBISHI OUTLANDER 2007 - 2012 (ZG-ZH)
MITSUBISHI OUTLANDER 2013 - 2018 (ZJ-ZK)
MITSUBISHI PAJERO 2006 - 2015 (NS-NT-NW)
MITSUBISHI PAJERO 2015 - 2021 (NT-NX)
MITSUBISHI PAJERO SPORT 2016 - 2018 (KR - KS - QE)
MITSUBISHI TRITON 2007 - 2013 (ML)
MITSUBISHI TRITON 2013 - 2015 (MN)
MITSUBISHI TRITON 2015 - 2018 (MQ)
MITSUBISHI TRITON 2019 - 2021 (MR)
NISSAN 200SX 1999 - 2002 (S14)
NISSAN 350Z 2003 - 2005 (Z33)
NISSAN 350Z 2006 - 2008 (Z33)
NISSAN 370Z 2009 - 2011 (Z34)
NISSAN DUALIS 2007 - 2013 (J10)
NISSAN ELGRAND 2001 - 2004 (E51)
NISSAN ELGRAND 2005 - 2010 (E51)
NISSAN JUKE 2013 - 2015 (F15)
NISSAN JUKE 2016 - 2018 (F15)
NISSAN MAXIMA 1995 - 2003 (A33)
NISSAN MICRA 2003 - 2009 (K12)
NISSAN MURANO 2005 - 2008 (Z50)
NISSAN MURANO 2009 - 2011 (Z51)
NISSAN NAVARA 2005 - 2015 (D22-D40)
NISSAN NAVARA 2015 - 2019 (D23 - NP300) RX-DX MODELS
NISSAN NAVARA 2019 - 2020 (D23)
NISSAN PATHFINDER 1996 - 2005 (R50)
NISSAN PATHFINDER 2003 - 2004 (WX-WX2)
NISSAN PATHFINDER 2005 - 2013 (R51)
NISSAN PATROL 1998 - 2009 (Y61)
NISSAN PATROL 2010 - 2013 (Y61)
NISSAN PULSAR 2013 - 2016 (C12)
NISSAN SKYLINE 1999 - 2002 (R34)
NISSAN SKYLINE 2001 - 2004 (V35)
NISSAN SKYLINE 2005 - 2007 (V35)
NISSAN TIIDA 2006 - 2011 (C2)
NISSAN XTRAIL 2003 - 2007 (T30)
NISSAN XTRAIL 2007 - 2013 (T31)
NISSAN XTRAIL 2019 - 2020 (T32)
PEUGEOT 4008 2010 - 2014 (No Chassis Code)
PEUGEOT 4008 2014 - 2017 (No Chassis Code)
PONTIAC FIREBIRD 1993 - 2002 (5th GEN)
PONTIAC GRAND AM 1992 - 1997 (3rd GEN)
PORSCHE CAYENNE 2002 - 2012 (9PA)
PROTON GEN2 2005 - 2009 (CM)
PROTON PERSONA 1999 - 2004 (CM)
PROTON PREVE + SUPRIMA 2012 - 2015 (CR)
PROTON SATRIA (Incl GTI) 1999 - 2004 (BS)
PROTON SAVVY 2005 - 2009 (BT - BT S2)
SAAB 93 1998 - 2004 (440)
SAAB 93 2004 - 2014 (442)
SAAB 95 2000 - 2005 (YS3E)
SAAB 95 2005 - 2011 (YS3G)
SAAB 97 2006 - 2011 (No Chassis Code)
SSANGYONG ACTYON 2006 - 2013 (100 Series)
SSANGYONG KORANDO 2011 - 2012 (C200)
SSANGYONG KORANDO 2013 - 2015 (C200)
SSANGYONG KYRON 2006 - 2011 (D100)
SSANGYONG REXTON 2006 - 2011 (Y250)
SSANGYONG STAVIC 2006 - 2012 (A100)
SSANGYONG STAVIC 2013 - 2015 (A100)
SUBARU BRZ 2017 - 2020 (POST-FACELIFT)
SUBARU FORESTER 1998 - 2006 (SF - SG)
SUBARU FORESTER 2007 - 2012 (SH)
SUBARU FORESTER 2013 - 2014 (SJ)
SUBARU FORESTER 2015 - 2018 (SJ)
SUBARU GL (Incl DL) 1981 - 1989 (No Chassis Code)
SUBARU IMPREZA 2016 - 2018 (GK-GT)
SUBARU IMPREZA (Inc WRX) 1993 - 2006 (GC-GD-GG)
SUBARU IMPREZA (Inc WRX) 2007 - 2012 (GE-GH-GR-GV)
SUBARU IMPREZA (Inc WRX) 2012 - 2014 (GP-GJ)
SUBARU IMPREZA (Inc WRX) 2015 - 2016 (GP-GJ)
SUBARU LEVORG 2016 - 2018 (V1)
SUBARU LIBERTY (Inc Outback) 1995 - 2003 (BE-BH-BT)
SUBARU LIBERTY (Inc Outback) 2004 - 2005 (BL-BP)
SUBARU LIBERTY (Inc Outback) 2006 - 2008 (BL-BP)
SUBARU LIBERTY (Inc Outback) 2009 - 2014 (BM-BR) WITH NAV
SUBARU LIBERTY (Inc Outback) 2009 - 2014 (BM-BR) WITHOUT NAV
SUBARU LIBERTY (Inc Outback) 2015 - 2017 (BN-BS)
SUBARU LIBERTY (Inc Outback) 2018 - 2020 (BN-BS)
SUBARU WRX (Inc STI) 2015 - 2018 (VA)
SUBARU XV 2012 - 2014 (GP)
SUBARU XV 2015 - 2016 (GP Facelift)
SUBARU XV 2017 - 2021 (GT)
SUZUKI BALENO 2016 - 2018 (EW)
SUZUKI GRAND VITARA 2003 - 2005 (SQ625)
SUZUKI GRAND VITARA 2005 - 2014 (JB)
SUZUKI GRAND VITARA 2015 - 2018 (JB)
SUZUKI KIZASHI 2010 - 2014 (FR)
SUZUKI LIANA 2005 - 2008 (RH416 - RH518)
SUZUKI SWIFT 2006 - 2010 (RS416)
SUZUKI SWIFT 2011 - 2016 (FZ)
SUZUKI SWIFT 2017 - 2020 (AZ)
SUZUKI SX4 (Incl S-Cross) 2007 - 2011 (GYB - GYC)
SUZUKI SX4 (Incl S-Cross) 2014 - 2016 (GYA)
SUZUKI VITARA 2015 - 2016 (LY)
SUZUKI XL7 2007 - 2009 (JA)
TOYOTA 86 2017 - 2020 (POST-FACELIFT)
TOYOTA ALPHARD 2008 - 2014 (AH20 Series)
TOYOTA ALPHARD 2015 - 2017 (AH30 Series)
TOYOTA AURION 2006 - 2011 (XV40 Series)
TOYOTA AURION 2012 - 2015 (XV50 Series)
TOYOTA AURION 2015 - 2017 (XV50 Series)
TOYOTA C-HR 2017 - 2019 (AX10 Series)
TOYOTA CAMRY 2002 - 2006 (XV30 Series)
TOYOTA CAMRY 2007 - 2011 (XV40 Series)
TOYOTA CAMRY 2012 - 2017 (XV50 Series)
TOYOTA CAMRY 2018 - 2020 (XV70 Series)
TOYOTA CELICA 2000 - 2005 (T230 Series)
TOYOTA COROLLA 1998 - 2002 (E110 Series)
TOYOTA COROLLA 2003 - 2009 (E140 - E160 Series)
TOYOTA COROLLA 2009 - 2012 (E120 Series)
TOYOTA COROLLA HATCH 2013 - 2015 (E180 Series)
TOYOTA COROLLA HATCH 2015 - 2018 (E180 - E200 Series)
TOYOTA COROLLA SEDAN 2014 - 2016 (E170 Series)
TOYOTA COROLLA SEDAN 2017 - 2018 (E170 Series)
TOYOTA ECHO 2000 - 2004 (XP10 Series)
TOYOTA ESTIMA 2000 - 2005 (XR30-XR40 Series)
TOYOTA ESTIMA 2006 - 2016 (XR50 Series)
TOYOTA FORTUNER 2015 - 2019 (AN150 - AN160 Series)
TOYOTA HIACE 2005 - 2019 (H200 Series)
TOYOTA HILUX 1997 - 2004 (N140 - N150 - N160 - N170 Series)
TOYOTA HILUX 2005 - 2010 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2011 - 2013 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2013 - 2015 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2015 - 2020 (AN120 - AN130 Series)
TOYOTA HILUX 2020 - 2021 (AN120 - AN130 Series)
TOYOTA KLUGER 2003 - 2006 (XU20 Series)
TOYOTA KLUGER 2007 - 2013 (XU40 Series)
TOYOTA KLUGER 2014 - 2019 (XU50 Series)
TOYOTA LANDCRUISER 2001 - 2008 (100 Series)
TOYOTA LANDCRUISER 2002 - 2009 (120 Series)
TOYOTA LANDCRUISER 2008 - 2012 (200 Series)
TOYOTA LANDCRUISER 2013 - 2015 (200 Series)
TOYOTA LANDCRUISER 2016 - 2021 (200 Series)
TOYOTA LANDCRUISER PRADO 2002 - 2009 (120 Series)
TOYOTA LANDCRUISER PRADO 2009 - 2013 (150 Series with NAV)
TOYOTA LANDCRUISER PRADO 2009 - 2013 (150 Series without NAV)
TOYOTA LANDCRUISER PRADO 2013 - 2017 (150 Series)
TOYOTA LANDCRUISER PRADO 2017 - 2020 (150 Series)
TOYOTA MR2 2000 - 2005 (W30 Series)
TOYOTA PRIUS 1997 - 2003 (XW10 Series)
TOYOTA PRIUS 2004 - 2009 (XW20 Series)
TOYOTA PRIUS 2010 - 2015 (XW30 Series)
TOYOTA PRIUS 2017 - 2019 (XW50 Series)
TOYOTA PRIUS C 2012 - 2018 (XP130 Series)
TOYOTA PRIUS V 2012 - 2015 (ZVW40R Series)
TOYOTA PRIUS V 2015 - 2019 (ZVW40- ZVW41 Series)
TOYOTA RAV4 2001 - 2005 (XA20 Series)
TOYOTA RAV4 2006 - 2011 (XA30 Series)
TOYOTA RAV4 2012 - 2013 (XA40 Series)
TOYOTA RAV4 2014 - 2018 (XA40 Series)
TOYOTA RUKUS 2010 - 2014 (E150 Series)
TOYOTA TARAGO 2005 - 2017 (XR50 Series)
TOYOTA TUNDRA 2007 - 2013 (XK50 Series)
TOYOTA TUNDRA 2014 - 2017 (XK50 Series)
TOYOTA YARIS 2005 - 2011 (XP90 Series)
TOYOTA YARIS 2012 - 2014 (XP90 Series)
TOYOTA YARIS 2014 - 2017 (XP130 Series)
TOYOTA YARIS 2018 - 2019 (XP130 Series)
VOLKSWAGEN AMAROK 2011 - 2015 (2H Series)
VOLKSWAGEN BEETLE 2013 - 2015 (1L Series)
VOLKSWAGEN CADDY 2005 - 2015 (2K Series)
VOLKSWAGEN EOS 2005 - 2013 (1F)
VOLKSWAGEN GOLF (Incl GTI) 1999 - 2004 (Mk 4 (1K Series))
VOLKSWAGEN GOLF (Incl GTI) 2005 - 2013 (Mk 5 - Mk 6 (5K Series))
VOLKSWAGEN JETTA 1999 - 2004 (A4 Series)
VOLKSWAGEN JETTA 2005 - 2015 (A5 - A6 Series)
VOLKSWAGEN PASSAT 1999 - 2004 (B5 Series)
VOLKSWAGEN PASSAT 2005 - 2014 (B6 - B7 Series)
VOLKSWAGEN POLO 2005 - 2009 (6Q - 9N - 9N3 Series)
VOLKSWAGEN POLO 2010 - 2014 (6R Series)
VOLKSWAGEN TIGUAN 2007 - 2016 (5N Series)
VOLKSWAGEN TOUAREG 2004 - 2010 (7L)
VOLKSWAGEN TRANSPORTER (Incl MULTIVAN or CARAVELLE) 2015 - 2019 (T6 Series)
VOLVO S60 2001 - 2009 (1st Generation)
VOLVO S80 1998 - 2006 (1st Generation)
VOLVO V70 2000 - 2004 (2nd Generation)
VOLVO XC70 2003 - 2007 (2nd Generation)
VOLVO XC90 2002 - 2014 (1st Generation)
SKU PACSWICP5
Barcode # 609098813860
Brand Pac Audio
Shipping Weight 1.5000kg

Universal Can-Bus Swc Interface

SKU: PACSWICP5
Sale price
$249.00
PayPal Checkout
4 payments of $62.25

afterpay More info.

Make 4 payments of $62.25 over 8 weeks and get it now!

zipMoney
From $10 / week
Afterpay
4 payments of $62.25

Calculate Shipping

Selected Part Number: PACSWICP5
General Product Information

Steering Wheel Control Interface


Retain your factory audio steering wheel controls and rear seat controls with one of the most advanced steering wheel interfaces available from PAC.

Works With Analog Vehicles

Based on the reliability of PAC long line of steering wheel retention interfaces, the SWI-CP5 allows easy retention of your steering wheel mounted audio control buttons in vehicles featuring analogue (resistive) wiring styles.


With added ability to program each button for two functions, you can now double your steering wheel controls with ease!

Ready For Todays Data Vehicles

If your vehicle features more complex data network, there’s a good chance your audio mounted steering wheel buttons are data based. With its data network compatibility, the SWI-CP5 allows easy retention of audio steering wheel buttons for your aftermarket radio.


Compatible vehicle networks including:

  • GMLAN
  • CLASS II
  • LIN-BUS
  • Serial Data
  • I-BUS
  • CAN BUS

(Check vehicle application listing for compatibility information)

Programming Is Easy as 1,2,3

Programming is made easy with select vehicle profiles preloaded which can be easily setup using the DIP switch settings found on the module.


Simply set the switches and plug the module in to the supplied harness (requires to be hardwired into the vehicle or can be used with select plug and play harnesses avail separately in packages) and away you go.


No preset available? Want to customize your steering wheel button features?

No worries!

You can easily manually map your vehicles buttons into the vehicle and customise the button features* (dependant on the aftermarket radios remote control features. See Installation manual for total list of features)


Are you regularly programming the same kind of vehicles? want to backup and save your configuration for easy firmware updating in the future?

With the PAC SWI-CP5's Android and iOS application, you can easily configure and program your steering wheel buttons straight from your mobile or tablet device

(required USB Lead, not included)

Major Brands Supported

Designed to work with a wide range of vehicles,

the PAC SWI-CP5 is compatible with the following brands of aftermarket radios including

  • Alpine
  • Clarion
  • Fusion
  • JVC
  • Kenwood
  • Lightning Audio
  • Nakamichi
  • Pioneer
  • Sony
  • Stinger

and more!

Feature Packed

Speed through your radio replacement installation when using the SWI-RC-1 to retain your factory steering wheel controls.

  • Configure using the Web Application, Android Application, Apple Application, USB flash drive or manual programming.
  • Compatible in vehicles equipped with LAN, LIN, CAN, Class II, Analog or Serial Data SWC.
  • Create and save custom vehicle configuration files for later use.
  • Ability to assign two radio functions to one SWC button.
  • Audible feedback for programming confirmation.
  • Highly visible tricolor LED to keep the user informed of the modules status.
  • Retains memory even if power is lost.
  • Equipped with a manual learning function for compatibility with unlisted analog vehicles.

What Do You Get?

The PAC ControlPRO 5 SWI-CP5 includes

  • Vehicle Interface
  • Universal Bare Wire Harness
  • Instruction Manual
  • USB OTG Lead


Compatibility Notes

  • CAN-BUS vehicles cannot be manually programmed.
  • ACC 12v output only available on CAN vehicles where IGN data is available
  • Buttons can only be remapped to what is available selected brand of aftermarket radio
  • FORD, EXPLORER 2002-2005 — Models with 24 Pin Connector
  • FORD, FIESTA 2002-2006 Models with 3 section headunit
  • FORD, FIESTA 2009-2016 — Models with monochrome screen (Clock & Trip screen access is lost)
  • FORD, FOCUS (Incl XR5) 1999-2004 — Models with 17 Pin Connector
  • FORD, FOCUS (Incl XR5) 2005-2008 — Models with 24 Pin Connector
  • HOLDEN, BARINA 2012-2016 — Non MyLink Models (Will lose access to vehicle settings)
  • HOLDEN, BARINA SPARK 2010-2016 — 2010-2012 Models with 44 Pin Connector
  • HOLDEN, CAPTIVA 7 2006-2015 — Nav Models will lose screen
  • HOLDEN, COLORADO (Incl 7) 2012-2013 — Models with 16 Pin Connector
  • HOLDEN, COLORADO (Incl 7) 2014-2016 — Models with 16 Pin Connector
  • HOLDEN, VIVA, 2006-2011 — Models with 18 Pin Connector
  • HONDA, ACCORD EURO 2008-2015 — Models with 24 Pin Connector
  • HONDA, CITY, 2015-2018 — Models with mechless head unit
  • HONDA, CIVIC HATCH, 2006-2011 — Will not retain OE display above head unit
  • HONDA, CIVIC HATCH, 2012-2015 — Nav models – Unable to adjust clock on HUD
  • HONDA, CRV, 2007-2011 — Models with 20 Pin Connector
  • HONDA, CRV, 2012-2015 — Nav models – Unable to adjust clock on HUD
  • HONDA, HRV, 2015-2017 — Models with mechless head unit
  • HONDA, HRV, 2017-2018 —Models with mechless head unit
  • HONDA, JAZZ, 2008-2013 — Models with 24 Pin Connector
  • HONDA, JAZZ, 2014-2016 — Models with mechless head unit
  • HONDA, JAZZ, 2017-2018 — Models with mechless head unit with 24 Pin Connector
  • HONDA, MDX, 2001-2006 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2005-2009 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2009-2013 — Models with 20 Pin Connector
  • HONDA, ODYSSEY, 2014-2016 — Unable to adjust clock in cluster
  • HYUNDAI, ACCENT, 2006-2008 — Models with 24 Pin Connector
  • HYUNDAI, ACCENT, 2011-2018 — Models with 24 Pin Connector
  • HYUNDAI, ELANTRA, 2007-2010 — Models with 24 Pin Connector
  • HYUNDAI, ELANTRA, 2011-2013 — Models with 24 Pin Connector
  • HYUNDAI, GRANDEUR, 2006-2010 — Models with 24 Pin Connector
  • HYUNDAI, i30, 2012- 2016 — Nav Models with 24 Pin Connector
  • HYUNDAI, ILOAD (Incl IMAX), 2016-2018 — Models with 38 Pin Connector
  • HYUNDAI, SONATA, 2006-2008 — Models with 24 Pin Connector
  • IVECO, DAILY, 2015-2017 — Models with 12 Pin Connector
  • KIA, CARNIVAL (Incl Grand), 2006-2015 — Models with mini ISO Connector
  • KIA, CERATO, 2010-2013 — Models with mini ISO Connector
  • KIA, SORENTO, 2009-2012 — Non Amplified Models
  • LAND ROVER, DISCOVERY III, 2005-2010 — Non Amplified Models
  • LAND ROVER, FREELANDER II, 2007-2011 — Non Amplified Models
  • LAND ROVER, RANGE ROVER, 2005-2010 — Non Amplified Models
  • LAND ROVER, RANGE ROVER 2011-2014 — Non Amplified Models
  • LEXUS, IS, 1999-2005 — Non Navigation Models
  • MAZDA, 3, 2009-2013 — Non Amplified Models (Will not retain clock & trip display)
  • MAZDA, 6, 2010-2012 — Non Amplified Models (Will not retain clock & trip display)
  • MAZDA, MX5, 1998-2005 — Non Amplified Models
  • MAZDA, MX5, 2006-2008 — Non Amplified Models
  • MAZDA, MX5, 2009-2013 — Non Amplified Models
  • MAZDA, TRIBUTE, 2001-2005 — Models with 14 Pin Connector
  • MITSUBISHI, ASX, 2013-2018 — Amplified Models (AXTO-MI2 also required)
  • MITSUBISHI, LANCER (Inc Evolution), 2014-2018 — Amplified Models (AXTO-MI2 also required)
  • MITSUBISHI, MAGNA (Inc Verada), 1997-2005 — Models with 6 Pin Connector
  • MITSUBISHI, OUTLANDER, 2013-2018 — Amplified Models (AXTO-MI3 also required)
  • MITSUBISHI, PAJERO SPORT, 2015-2018 — Amplified Models (AXTO-MI3 also required)MITSUBISHI, TRITON, 2007-2013 — Models with trip display
  • MITSUBISHI, TRITON, 2013-2015 — Models with trip display
  • NISSAN, 350Z, 2006-2008 — Models with 32 Pin Connector
  • NISSAN, MAXIMA, 1995-2003 — Models with 32 Pin Connector
  • NISSAN, PATHFINDER, 2005-2013 — Models with 16A Connector
  • NISSAN, SKYLINE, 2001-2004 — Models with 16 Pin Connector
  • PORSCHE 911 2005 – 2012 (997) — 2005 – 2009 Models Only
  • SUZUKI, GRAND VITARA, 2005-2014 — 2011+ Models
  • SUZUKI, SWIFT, 2011-2016 — 2011+ Models
  • TOYOTA, CAMRY, 2018-2018 — Models with 28 Pin Connectors

Product Overview Video


Important Product Compatibility Information
Retain Factory Steering Wheel Audio Controls?

YES – Will retain Steering Wheel Audio Controls with Select Aftermarket Radios

Plug & Play

NO

Retain Parking Sensors?

NO – If vehicle OEM radio was generating the parking sensor tones. If parking sensors are not part of the factory radio, they should not be effected

Retain Factory Amplifier?

NO

Retain vehicle OE clock & trip display?

NO – If OEM Radio Controlled This Feature

Vehicle Notes

FORD, EXPLORER 2002-2005 — Models with 24 Pin Connector
FORD, FIESTA 2002-2006 Models with 3 section headunit
FORD, FIESTA 2009-2016 — Models with monochrome screen (Clock & Trip screen access is lost)
FORD, FOCUS (Incl XR5) 1999-2004 — Models with 17 Pin Connector
FORD, FOCUS (Incl XR5) 2005-2008 — Models with 24 Pin Connector
HOLDEN, BARINA 2012-2016 — Non MyLink Models (Will lose access to vehicle settings)
HOLDEN, BARINA SPARK 2010-2016 — 2010-2012 Models with 44 Pin Connector
HOLDEN, CAPTIVA 7 2006-2015 — Nav Models will lose screen
HOLDEN, COLORADO (Incl 7) 2012-2013 — Models with 16 Pin Connector
HOLDEN, COLORADO (Incl 7) 2014-2016 — Models with 16 Pin Connector
HOLDEN, VIVA, 2006-2011 — Models with 18 Pin Connector
HONDA, ACCORD EURO 2008-2015 — Models with 24 Pin Connector
HONDA, CITY, 2015-2018 — Models with mechless head unit
HONDA, CIVIC HATCH, 2006-2011 — Will not retain OE display above head unit
HONDA, CIVIC HATCH, 2012-2015 — Nav models – Unable to adjust clock on HUD
HONDA, CRV, 2007-2011 — Models with 20 Pin Connector
HONDA, CRV, 2012-2015 — Nav models – Unable to adjust clock on HUD
HONDA, HRV, 2015-2017 — Models with mechless head unit
HONDA, HRV, 2017-2018 —Models with mechless head unit
HONDA, JAZZ, 2008-2013 — Models with 24 Pin Connector
HONDA, JAZZ, 2014-2016 — Models with mechless head unit
HONDA, JAZZ, 2017-2018 — Models with mechless head unit with 24 Pin Connector
HONDA, MDX, 2001-2006 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2005-2009 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2009-2013 — Models with 20 Pin Connector
HONDA, ODYSSEY, 2014-2016 — Unable to adjust clock in cluster
HYUNDAI, ACCENT, 2006-2008 — Models with 24 Pin Connector
HYUNDAI, ACCENT, 2011-2018 — Models with 24 Pin Connector
HYUNDAI, ELANTRA, 2007-2010 — Models with 24 Pin Connector
HYUNDAI, ELANTRA, 2011-2013 — Models with 24 Pin Connector
HYUNDAI, GRANDEUR, 2006-2010 — Models with 24 Pin Connector
HYUNDAI, i30, 2012- 2016 — Nav Models with 24 Pin Connector
HYUNDAI, ILOAD (Incl IMAX), 2016-2018 — Models with 38 Pin Connector
HYUNDAI, SONATA, 2006-2008 — Models with 24 Pin Connector
IVECO, DAILY, 2015-2017 — Models with 12 Pin Connector
KIA, CARNIVAL (Incl Grand), 2006-2015 — Models with mini ISO Connector
KIA, CERATO, 2010-2013 — Models with mini ISO Connector
KIA, SORENTO, 2009-2012 — Non Amplified Models
LAND ROVER, DISCOVERY III, 2005-2010 — Non Amplified Models
LAND ROVER, FREELANDER II, 2007-2011 — Non Amplified Models
LAND ROVER, RANGE ROVER, 2005-2010 — Non Amplified Models
LAND ROVER, RANGE ROVER 2011-2014 — Non Amplified Models
LEXUS, IS, 1999-2005 — Non Navigation Models
MAZDA, 3, 2009-2013 — Non Amplified Models (Will not retain clock & trip display)
MAZDA, 6, 2010-2012 — Non Amplified Models (Will not retain clock & trip display)
MAZDA, MX5, 1998-2005 — Non Amplified Models
MAZDA, MX5, 2006-2008 — Non Amplified Models
MAZDA, MX5, 2009-2013 — Non Amplified Models
MAZDA, TRIBUTE, 2001-2005 — Models with 14 Pin Connector
MITSUBISHI, ASX, 2013-2018 — Amplified Models (AXTO-MI2 also required)
MITSUBISHI, LANCER (Inc Evolution), 2014-2018 — Amplified Models (AXTO-MI2 also required)
MITSUBISHI, MAGNA (Inc Verada), 1997-2005 — Models with 6 Pin Connector
MITSUBISHI, OUTLANDER, 2013-2018 — Amplified Models (AXTO-MI3 also required)
MITSUBISHI, PAJERO SPORT, 2015-2018 — Amplified Models (AXTO-MI3 also required)MITSUBISHI, TRITON, 2007-2013 — Models with trip display
MITSUBISHI, TRITON, 2013-2015 — Models with trip display
NISSAN, 350Z, 2006-2008 — Models with 32 Pin Connector
NISSAN, MAXIMA, 1995-2003 — Models with 32 Pin Connector
NISSAN, PATHFINDER, 2005-2013 — Models with 16A Connector
NISSAN, SKYLINE, 2001-2004 — Models with 16 Pin Connector
PORSCHE 911 2005 – 2012 (997) — 2005 – 2009 Models Only
SUZUKI, GRAND VITARA, 2005-2014 — 2011+ Models
SUZUKI, SWIFT, 2011-2016 — 2011+ Models
TOYOTA, CAMRY, 2018-2018 — Models with 28 Pin Connectors

Product Vehicle Applications
What Fits My Car

This product is compatbile with the following vehicles. If no vehicles are listed, this product is universal product (non vehicle specific)
Vehicle Make Vehicle Model Vehicle Year + Vehicle Chassis Code
AUDI A4 (Incl S4) 2001 - 2008 (B6-B7)
BMW 3 SERIES (Incl M3) 1997 - 2005 (E46)
BMW 5 SERIES (Incl M5) 1996 - 2003 (E39)
BMW 5 SERIES (Incl M5) 2004 - 2011 (E60)
BMW 7 SERIES 1994 - 2001 (E38)
BMW X5 2000 - 2005 (E53)
BMW X5 2006 - 2011 (E70)
BMW Z3 1996 - 2002 (E36-E37-E38)
BMW Z4 2003 - 2008 (E85-E86)
CADILLAC ESCALADE 1999 - 2001 (FIRST GEN)
CADILLAC ESCALADE 2002 - 2006 (SECOND GEN)
CHEVROLET AVALANCHE 1999 - 2002 (FIRST GEN)
CHEVROLET AVALANCHE 2003 - 2006 (SECOND GEN)
CHEVROLET AVALANCHE 2007 - 2011 (THIRD GEN)
CHEVROLET CAMARO 1990 - 1992 (3RD GEN)
CHEVROLET CAMARO 1993 - 2002 (4TH GEN)
CHEVROLET CORVETTE 1984 - 1989 (C4)
CHEVROLET CORVETTE 1990 - 1996 (C4)
CHEVROLET CORVETTE 1997 - 2004 (C5)
CHEVROLET CORVETTE 2005 - 2013 (C6)
CHEVROLET SSR 2003 - 2006 (Super Sports Roadster)
CHEVROLET SUBURBAN 2000 - 2006 (NINTH GEN)
CHRYSLER NEON 1996 - 1999 (FIRST GEN)
CHRYSLER NEON 2000 - 2006 (SECOND GEN)
CHRYSLER PROWLER 2002 - 2002 (GRRRR…)
CHRYSLER PT CRUISER 2001 - 2005 (FIRST GEN)
CHRYSLER PT CRUISER 2006 - 2011 (SECOND GEN)
CHRYSLER VOYAGER (Incl GRAND VOYAGER) 1996 - 2001 (3RD GEN)
CHRYSLER VOYAGER (Incl GRAND VOYAGER) 2001 - 2007 (4TH GEN)
CITROEN DS3 2009 - 2016 (FIRST GEN)
DODGE CALIBER 2006 - 2009 (FIRST GEN)
DODGE RAM 2002 - 2005 (3RD GEN)
FIAT DUCATO 2015 - 2018 (FOURTH GEN)
FORD COUGAR 1999 - 2000 (MK1)
FORD ESCAPE 2001 - 2007 (FIRST GEN)
FORD ESCAPE 2006 - 2011 (2ND GEN)
FORD EXPLORER 1995 - 2001 (UN - US)
FORD EXPLORER 2002 - 2005 (UT - UX)
FORD EXPLORER 2006 - 2011 (UZ)
FORD F SERIES 1995 - 2004 (10th Gen)
FORD F SERIES 2005 - 2008 (11th Gen)
FORD FALCON 1998 - 2002 (AU)
FORD FALCON 2003 - 2008 (BA-BF)
FORD FALCON 2009 - 2011 (FG)
FORD FIESTA 2009 - 2016 (WS-WT-WZ)
FORD FOCUS (Incl XR5) 2005 - 2007 (LS-LT)
FOTON TUNLAND 2012 - 2016 (E3)
GREAT WALL STEED 2016 - 2018 (NBP)
GREAT WALL V200 + V240 2009 - 2014 (K2)
GREAT WALL X240 2010 - 2011 (H5)
HARLEY DAVIDSON STREET GLIDE 1998 - 2013 (MOTORBIKE)
HARLEY DAVIDSON ULTRA GLIDE 1998 - 2013 (MOTORBIKE)
HOLDEN BARINA 2006 - 2011 (TK)
HOLDEN BARINA 2012 - 2016 (TM)
HOLDEN BARINA SPARK 2010 - 2016 (MJ)
HOLDEN CAPTIVA 7 (Incl Variants) 2006 - 2015 (CG)
HOLDEN COLORADO (Incl 7) 2012 - 2013 (RG)
HOLDEN COLORADO (Incl 7) 2014 - 2016 (RG)
HOLDEN COMMODORE 1997 - 2002 (VT-VX)
HOLDEN COMMODORE 2002 - 2007 (VY-VZ)
HOLDEN EPICA 2006 - 2011 (EP)
HOLDEN EQUINOX 2017 - 2018 (EQ)
HOLDEN TIGRA 2004 - 2009 (XC)
HOLDEN VECTRA 2003 - 2011 (ZC)
HOLDEN VIVA 2006 - 2011 (JF)
HONDA ACCORD 1989 - 1993 (4TH GEN)
HONDA ACCORD 1993 - 1997 (5TH GEN)
HONDA ACCORD 2003 - 2007 (7TH GEN)
HONDA ACCORD 2008 - 2012 (8TH GEN)
HONDA ACCORD EURO 2003 - 2007 (7TH GEN)
HONDA ACCORD EURO 2008 - 2015 (8TH GEN)
HONDA CITY 2009 - 2013 (GM)
HONDA CITY 2013 - 2015 (GM)
HONDA CITY 2015 - 2019 (GM)
HONDA CIVIC HATCH 2001 - 2005 (7TH GEN)
HONDA CIVIC HATCH 2006 - 2011 (8TH GEN)
HONDA CIVIC HATCH 2012 - 2015 (9TH GEN)
HONDA CIVIC HATCH 2015 - 2016 (9TH GEN)
HONDA CIVIC SEDAN 2001 - 2005 (7TH GEN)
HONDA CIVIC SEDAN 2006 - 2011 (8TH GEN)
HONDA CIVIC SEDAN 2012 - 2015 (9TH GEN)
HONDA CRV 1997 - 2006 (RD)
HONDA CRV 2007 - 2011 (RE)
HONDA CRV 2012 - 2015 (RM)
HONDA CRZ 2010 - 2014 (ZF)
HONDA HRV 2015 - 2017 (2ND GEN)
HONDA HRV 2017 - 2019 (2ND GEN)
HONDA INSIGHT 2009 - 2013 (ZE)
HONDA INTEGRA 1993 - 2001 (DB - DC1 - DC2)
HONDA INTEGRA 2002 - 2006 (DC5)
HONDA JAZZ 2001 - 2007 (GD)
HONDA JAZZ 2008 - 2013 (GE)
HONDA JAZZ 2014 - 2016 (GF)
HONDA JAZZ 2017 - 2019 (GF)
HONDA LEGEND 1990 - 1996 (KA7-KA8)
HONDA LEGEND 1996 - 2003 (KA9)
HONDA MDX 2001 - 2006 (YD1)
HONDA ODYSSEY 1995 - 1999 (1ST GEN (RA1 - RA5))
HONDA ODYSSEY 2004 - 2009 (3RD GEN (RB1 - RB2))
HONDA ODYSSEY 2009 - 2013 (4TH GEN (RB3 - RB4))
HONDA ODYSSEY 2014 - 2018 (5TH GEN (RC1 - RC2))
HONDA PRELUDE 1991 - 1996 (4TH GEN (BA - BB))
HONDA PRELUDE 1997 - 2001 (5TH GEN (BB5-BB9))
HONDA S2000 1999 - 2011 (AP1 - AP2)
HUMMER H2 2002 - 2007 (H2)
HUMMER H2 2008 - 2011 (H2)
HYUNDAI ACCENT 2006 - 2008 (MC)
HYUNDAI ACCENT 2011 - 2019 (RB)
HYUNDAI ELANTRA 2007 - 2010 (HD)
HYUNDAI ELANTRA 2011 - 2013 (MD-MD2)
HYUNDAI ELANTRA 2014 - 2015 (MD3)
HYUNDAI ELANTRA 2016 - 2018 (AD)
HYUNDAI GETZ 2002 - 2010 (TB)
HYUNDAI GRANDEUR 2006 - 2010 (TG)
HYUNDAI i20 2010 - 2012 (PB)
HYUNDAI i20 2012 - 2015 (PB)
HYUNDAI i30 2007 - 2011 (FD)
HYUNDAI i30 2012 - 2016 (GD-GD2)
HYUNDAI i40 2012 - 2018 (VF-VF2-VF3)
HYUNDAI i45 2010 - 2012 (YF)
HYUNDAI ILOAD (Incl IMAX) 2008 - 2016 (TQ)
HYUNDAI ILOAD (Incl IMAX) 2016 - 2018 (TQ3-V Series II)
HYUNDAI ILOAD (Incl IMAX) 2018 - 2019 (TQ4)
HYUNDAI ix35 2010 - 2013 (LM)
HYUNDAI ix35 2014 - 2015 (LM) - WITH NAV
HYUNDAI ix35 2014 - 2015 (LM) - WITHOUT NAV
HYUNDAI SANTA FE 2001 - 2006 (SM)
HYUNDAI SANTA FE 2009 - 2012 (CM)
HYUNDAI SANTA FE 2012 - 2018 (DM)
HYUNDAI SONATA 1995 - 2001 (Y3)
HYUNDAI SONATA 2002 - 2005 (EF)
HYUNDAI SONATA 2006 - 2008 (NF)
HYUNDAI SONATA 2009 - 2011 (YF)
HYUNDAI TIBURON 1997 - 2002 (RD - RD2)
HYUNDAI TIBURON 2003 - 2008 (GK)
HYUNDAI TUCSON 2015 - 2018 (TL)
HYUNDAI VELOSTER 2012 - 2017 (1ST GEN)
ISUZU DMAX 2012 - 2016 (RT50 - RT85)
ISUZU DMAX 2016 - 2019 (RT50 - RT85)
ISUZU MUX 2013 - 2015 (RF10)
ISUZU MUX 2016 - 2017 (RF20)
IVECO DAILY 2007 - 2014 (5TH GEN)
IVECO DAILY 2015 - 2017 (6TH GEN)
IVECO DAILY 2018 - 2019 (6TH GEN)
JAGUAR S-TYPE 2000 - 2002 (No Chassis Code)
JAGUAR S-TYPE 2003 - 2008 (No Chassis Code)
JAGUAR X-TYPE 2002 - 2015 (No Chassis Code)
JEEP CHEROKEE 1994 - 2001 (XJ)
JEEP CHEROKEE 2001 - 2007 (KJ)
JEEP COMMANDER 2005 - 2008 (XK)
JEEP COMPASS 2007 - 2009 (MK)
JEEP GRAND CHEROKEE 1999 - 2004 (WJ-WG)
JEEP GRAND CHEROKEE 2005 - 2007 (WH-WK)
JEEP PATRIOT 2007 - 2009 (MK)
JEEP WRANGLER 1986 - 2004 (YJ - TJ)
JEEP WRANGLER 2003 - 2006 (TJ)
KIA CARNIVAL (Incl Grand) 1998 - 2005 (KV-II)
KIA CARNIVAL (Incl Grand) 2006 - 2015 (VQ)
KIA CERATO 2010 - 2012 (TD)
KIA CERATO 2013 - 2018 (YD)
KIA CERATO 2019 - 2021 (BD)
KIA MAGENTIS 2006 - 2010 (MG)
KIA OPTIMA 2006 - 2010 (MG)
KIA OPTIMA 2010 - 2013 (TF1)
KIA OPTIMA 2013 - 2015 (TF2)
KIA PICANTO 2016 - 2017 (TA)
KIA PRO CEED 2014 - 2015 (JD)
KIA RIO 2010 - 2014 (UB)
KIA RIO 2014 - 2017 (UB)
KIA RONDO 2007 - 2012 (UN)
KIA RONDO 2013 - 2018 (RP)
KIA SORENTO 2007 - 2008 (BL)
KIA SORENTO 2009 - 2012 (XM)
KIA SORENTO 2013 - 2015 (XM)
KIA SORENTO EX 2003 - 2009 (BL)
KIA SORENTO LX 2001 - 2003 (BL)
KIA SORENTO LX 2007 - 2009 (BL)
KIA SOUL 2009 - 2011 (AM)
KIA SOUL 2014 - 2018 (PS)
KIA SPORTAGE 2010 - 2015 (SL)
KIA SPORTAGE 2016 - 2018 (QL)
LAMBORGHINI GALLARDO 2005 - 2011 (No Chassis Code)
LAND ROVER DISCOVERY III 2005 - 2010 (L319)
LAND ROVER RANGE ROVER (Incl HSE - VOGUE) 2002 - 2012 (L322)
LEXUS ES 1992 - 1996 (XV10)
LEXUS ES 1997 - 2001 (XV20)
LEXUS ES 2002 - 2006 (XV30)
LEXUS GS 1998 - 2006 (S160)
LEXUS IS 1999 - 2005 (XE10)
LEXUS LX 1998 - 2007 (J100)
LEXUS RX 2003 - 2008 (XU30)
MAZDA 2 2007 - 2015 (DE)
MAZDA 3 2004 - 2009 (BK)
MAZDA 3 2009 - 2013 (BL)
MAZDA 3 2013 - 2016 (BM) - WITH MONOCHROME DISPLAY
MAZDA 323 1986 - 1994 (BF - BG)
MAZDA 6 2003 - 2005 (GG)
MAZDA 6 2005 - 2008 (GG)
MAZDA 6 2010 - 2012 (GH)
MAZDA BT-50 2015 - 2019 (UR) WITH 7inch NAV
MAZDA CX5 2015 - 2017 (KE)
MAZDA CX7 2006 - 2010 (ER)
MAZDA CX7 2010 - 2011 (ER)
MAZDA MPV 2000 - 2006 (LW)
MAZDA MX5 1998 - 2005 (NB)
MAZDA MX5 2006 - 2008 (NC)
MAZDA MX5 2009 - 2013 (ND)
MAZDA PREMACY 2000 - 2006 (1ST GEN)
MAZDA RX8 2004 - 2008 (FE)
MAZDA RX8 2008 - 2012 (FE)
MAZDA TRIBUTE 2001 - 2006 (1ST GEN)
MAZDA TRIBUTE 2006 - 2011 (2ND GEN)
MERCEDES A CLASS 2005 - 2007 (W169)
MERCEDES B CLASS 2005 - 2007 (W245)
MERCEDES B CLASS 2007 - 2011 (W245)
MERCEDES C CLASS 2000 - 2004 (W203)
MERCEDES C CLASS 2005 - 2008 (W203)
MERCEDES CLK 2002 - 2004 (W208)
MERCEDES CLK 2005 - 2011 (W209)
MERCEDES CLS 2005 - 2010 (W219)
MERCEDES E CLASS 2002 - 2007 (W211)
MERCEDES G CLASS 2006 - 2012 (W463)
MERCEDES GL CLASS 2006 - 2012 (X164)
MERCEDES M CLASS 1999 - 2004 (W163)
MERCEDES M CLASS 2005 - 2011 (W164)
MERCEDES R CLASS 2006 - 2012 (W251)
MERCEDES S CLASS 1998 - 2006 (W220)
MERCEDES SL CLASS 2005 - 2013 (R230)
MERCEDES SLK CLASS 2004 - 2011 (R171)
MERCEDES SPRINTER 2007 - 2018 (W906)
MERCEDES VITO (Inc VIANO or VALENTE) 2004 - 2007 (W639)
MERCEDES VITO (Inc VIANO or VALENTE) 2007 - 2015 (W639)
MITSUBISHI 380 2004 - 2011 (DB)
MITSUBISHI ASX 2010 - 2013 (XA)
MITSUBISHI ASX 2013 - 2019 (XB - XC)
MITSUBISHI CHALLENGER 2009 - 2013 (PB)
MITSUBISHI CHALLENGER 2013 - 2015 (PC)
MITSUBISHI DELICA 2007 - 2010 (5TH GEN)
MITSUBISHI LANCER (Inc Evolution) 2007 - 2013 (CJ)
MITSUBISHI LANCER (Inc Evolution) 2014 - 2018 (CF)
MITSUBISHI MAGNA (Inc Verada) 1997 - 2005 (TF)
MITSUBISHI MIRAGE 2013 - 2019 (LA)
MITSUBISHI OUTLANDER 2003 - 2006 (ZE-ZF)
MITSUBISHI OUTLANDER 2007 - 2012 (ZG-ZH)
MITSUBISHI OUTLANDER 2013 - 2018 (ZJ-ZK)
MITSUBISHI PAJERO 2006 - 2015 (NS-NT-NW)
MITSUBISHI PAJERO 2015 - 2021 (NT-NX)
MITSUBISHI PAJERO SPORT 2016 - 2018 (KR - KS - QE)
MITSUBISHI TRITON 2007 - 2013 (ML)
MITSUBISHI TRITON 2013 - 2015 (MN)
MITSUBISHI TRITON 2015 - 2018 (MQ)
MITSUBISHI TRITON 2019 - 2021 (MR)
NISSAN 200SX 1999 - 2002 (S14)
NISSAN 350Z 2003 - 2005 (Z33)
NISSAN 350Z 2006 - 2008 (Z33)
NISSAN 370Z 2009 - 2011 (Z34)
NISSAN DUALIS 2007 - 2013 (J10)
NISSAN ELGRAND 2001 - 2004 (E51)
NISSAN ELGRAND 2005 - 2010 (E51)
NISSAN JUKE 2013 - 2015 (F15)
NISSAN JUKE 2016 - 2018 (F15)
NISSAN MAXIMA 1995 - 2003 (A33)
NISSAN MICRA 2003 - 2009 (K12)
NISSAN MURANO 2005 - 2008 (Z50)
NISSAN MURANO 2009 - 2011 (Z51)
NISSAN NAVARA 2005 - 2015 (D22-D40)
NISSAN NAVARA 2015 - 2019 (D23 - NP300) RX-DX MODELS
NISSAN NAVARA 2019 - 2020 (D23)
NISSAN PATHFINDER 1996 - 2005 (R50)
NISSAN PATHFINDER 2003 - 2004 (WX-WX2)
NISSAN PATHFINDER 2005 - 2013 (R51)
NISSAN PATROL 1998 - 2009 (Y61)
NISSAN PATROL 2010 - 2013 (Y61)
NISSAN PULSAR 2013 - 2016 (C12)
NISSAN SKYLINE 1999 - 2002 (R34)
NISSAN SKYLINE 2001 - 2004 (V35)
NISSAN SKYLINE 2005 - 2007 (V35)
NISSAN TIIDA 2006 - 2011 (C2)
NISSAN XTRAIL 2003 - 2007 (T30)
NISSAN XTRAIL 2007 - 2013 (T31)
NISSAN XTRAIL 2019 - 2020 (T32)
PEUGEOT 4008 2010 - 2014 (No Chassis Code)
PEUGEOT 4008 2014 - 2017 (No Chassis Code)
PONTIAC FIREBIRD 1993 - 2002 (5th GEN)
PONTIAC GRAND AM 1992 - 1997 (3rd GEN)
PORSCHE CAYENNE 2002 - 2012 (9PA)
PROTON GEN2 2005 - 2009 (CM)
PROTON PERSONA 1999 - 2004 (CM)
PROTON PREVE + SUPRIMA 2012 - 2015 (CR)
PROTON SATRIA (Incl GTI) 1999 - 2004 (BS)
PROTON SAVVY 2005 - 2009 (BT - BT S2)
SAAB 93 1998 - 2004 (440)
SAAB 93 2004 - 2014 (442)
SAAB 95 2000 - 2005 (YS3E)
SAAB 95 2005 - 2011 (YS3G)
SAAB 97 2006 - 2011 (No Chassis Code)
SSANGYONG ACTYON 2006 - 2013 (100 Series)
SSANGYONG KORANDO 2011 - 2012 (C200)
SSANGYONG KORANDO 2013 - 2015 (C200)
SSANGYONG KYRON 2006 - 2011 (D100)
SSANGYONG REXTON 2006 - 2011 (Y250)
SSANGYONG STAVIC 2006 - 2012 (A100)
SSANGYONG STAVIC 2013 - 2015 (A100)
SUBARU BRZ 2017 - 2020 (POST-FACELIFT)
SUBARU FORESTER 1998 - 2006 (SF - SG)
SUBARU FORESTER 2007 - 2012 (SH)
SUBARU FORESTER 2013 - 2014 (SJ)
SUBARU FORESTER 2015 - 2018 (SJ)
SUBARU GL (Incl DL) 1981 - 1989 (No Chassis Code)
SUBARU IMPREZA 2016 - 2018 (GK-GT)
SUBARU IMPREZA (Inc WRX) 1993 - 2006 (GC-GD-GG)
SUBARU IMPREZA (Inc WRX) 2007 - 2012 (GE-GH-GR-GV)
SUBARU IMPREZA (Inc WRX) 2012 - 2014 (GP-GJ)
SUBARU IMPREZA (Inc WRX) 2015 - 2016 (GP-GJ)
SUBARU LEVORG 2016 - 2018 (V1)
SUBARU LIBERTY (Inc Outback) 1995 - 2003 (BE-BH-BT)
SUBARU LIBERTY (Inc Outback) 2004 - 2005 (BL-BP)
SUBARU LIBERTY (Inc Outback) 2006 - 2008 (BL-BP)
SUBARU LIBERTY (Inc Outback) 2009 - 2014 (BM-BR) WITH NAV
SUBARU LIBERTY (Inc Outback) 2009 - 2014 (BM-BR) WITHOUT NAV
SUBARU LIBERTY (Inc Outback) 2015 - 2017 (BN-BS)
SUBARU LIBERTY (Inc Outback) 2018 - 2020 (BN-BS)
SUBARU WRX (Inc STI) 2015 - 2018 (VA)
SUBARU XV 2012 - 2014 (GP)
SUBARU XV 2015 - 2016 (GP Facelift)
SUBARU XV 2017 - 2021 (GT)
SUZUKI BALENO 2016 - 2018 (EW)
SUZUKI GRAND VITARA 2003 - 2005 (SQ625)
SUZUKI GRAND VITARA 2005 - 2014 (JB)
SUZUKI GRAND VITARA 2015 - 2018 (JB)
SUZUKI KIZASHI 2010 - 2014 (FR)
SUZUKI LIANA 2005 - 2008 (RH416 - RH518)
SUZUKI SWIFT 2006 - 2010 (RS416)
SUZUKI SWIFT 2011 - 2016 (FZ)
SUZUKI SWIFT 2017 - 2020 (AZ)
SUZUKI SX4 (Incl S-Cross) 2007 - 2011 (GYB - GYC)
SUZUKI SX4 (Incl S-Cross) 2014 - 2016 (GYA)
SUZUKI VITARA 2015 - 2016 (LY)
SUZUKI XL7 2007 - 2009 (JA)
TOYOTA 86 2017 - 2020 (POST-FACELIFT)
TOYOTA ALPHARD 2008 - 2014 (AH20 Series)
TOYOTA ALPHARD 2015 - 2017 (AH30 Series)
TOYOTA AURION 2006 - 2011 (XV40 Series)
TOYOTA AURION 2012 - 2015 (XV50 Series)
TOYOTA AURION 2015 - 2017 (XV50 Series)
TOYOTA C-HR 2017 - 2019 (AX10 Series)
TOYOTA CAMRY 2002 - 2006 (XV30 Series)
TOYOTA CAMRY 2007 - 2011 (XV40 Series)
TOYOTA CAMRY 2012 - 2017 (XV50 Series)
TOYOTA CAMRY 2018 - 2020 (XV70 Series)
TOYOTA CELICA 2000 - 2005 (T230 Series)
TOYOTA COROLLA 1998 - 2002 (E110 Series)
TOYOTA COROLLA 2003 - 2009 (E140 - E160 Series)
TOYOTA COROLLA 2009 - 2012 (E120 Series)
TOYOTA COROLLA HATCH 2013 - 2015 (E180 Series)
TOYOTA COROLLA HATCH 2015 - 2018 (E180 - E200 Series)
TOYOTA COROLLA SEDAN 2014 - 2016 (E170 Series)
TOYOTA COROLLA SEDAN 2017 - 2018 (E170 Series)
TOYOTA ECHO 2000 - 2004 (XP10 Series)
TOYOTA ESTIMA 2000 - 2005 (XR30-XR40 Series)
TOYOTA ESTIMA 2006 - 2016 (XR50 Series)
TOYOTA FORTUNER 2015 - 2019 (AN150 - AN160 Series)
TOYOTA HIACE 2005 - 2019 (H200 Series)
TOYOTA HILUX 1997 - 2004 (N140 - N150 - N160 - N170 Series)
TOYOTA HILUX 2005 - 2010 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2011 - 2013 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2013 - 2015 (AN10 - AN20 - AN30 Series)
TOYOTA HILUX 2015 - 2020 (AN120 - AN130 Series)
TOYOTA HILUX 2020 - 2021 (AN120 - AN130 Series)
TOYOTA KLUGER 2003 - 2006 (XU20 Series)
TOYOTA KLUGER 2007 - 2013 (XU40 Series)
TOYOTA KLUGER 2014 - 2019 (XU50 Series)
TOYOTA LANDCRUISER 2001 - 2008 (100 Series)
TOYOTA LANDCRUISER 2002 - 2009 (120 Series)
TOYOTA LANDCRUISER 2008 - 2012 (200 Series)
TOYOTA LANDCRUISER 2013 - 2015 (200 Series)
TOYOTA LANDCRUISER 2016 - 2021 (200 Series)
TOYOTA LANDCRUISER PRADO 2002 - 2009 (120 Series)
TOYOTA LANDCRUISER PRADO 2009 - 2013 (150 Series with NAV)
TOYOTA LANDCRUISER PRADO 2009 - 2013 (150 Series without NAV)
TOYOTA LANDCRUISER PRADO 2013 - 2017 (150 Series)
TOYOTA LANDCRUISER PRADO 2017 - 2020 (150 Series)
TOYOTA MR2 2000 - 2005 (W30 Series)
TOYOTA PRIUS 1997 - 2003 (XW10 Series)
TOYOTA PRIUS 2004 - 2009 (XW20 Series)
TOYOTA PRIUS 2010 - 2015 (XW30 Series)
TOYOTA PRIUS 2017 - 2019 (XW50 Series)
TOYOTA PRIUS C 2012 - 2018 (XP130 Series)
TOYOTA PRIUS V 2012 - 2015 (ZVW40R Series)
TOYOTA PRIUS V 2015 - 2019 (ZVW40- ZVW41 Series)
TOYOTA RAV4 2001 - 2005 (XA20 Series)
TOYOTA RAV4 2006 - 2011 (XA30 Series)
TOYOTA RAV4 2012 - 2013 (XA40 Series)
TOYOTA RAV4 2014 - 2018 (XA40 Series)
TOYOTA RUKUS 2010 - 2014 (E150 Series)
TOYOTA TARAGO 2005 - 2017 (XR50 Series)
TOYOTA TUNDRA 2007 - 2013 (XK50 Series)
TOYOTA TUNDRA 2014 - 2017 (XK50 Series)
TOYOTA YARIS 2005 - 2011 (XP90 Series)
TOYOTA YARIS 2012 - 2014 (XP90 Series)
TOYOTA YARIS 2014 - 2017 (XP130 Series)
TOYOTA YARIS 2018 - 2019 (XP130 Series)
VOLKSWAGEN AMAROK 2011 - 2015 (2H Series)
VOLKSWAGEN BEETLE 2013 - 2015 (1L Series)
VOLKSWAGEN CADDY 2005 - 2015 (2K Series)
VOLKSWAGEN EOS 2005 - 2013 (1F)
VOLKSWAGEN GOLF (Incl GTI) 1999 - 2004 (Mk 4 (1K Series))
VOLKSWAGEN GOLF (Incl GTI) 2005 - 2013 (Mk 5 - Mk 6 (5K Series))
VOLKSWAGEN JETTA 1999 - 2004 (A4 Series)
VOLKSWAGEN JETTA 2005 - 2015 (A5 - A6 Series)
VOLKSWAGEN PASSAT 1999 - 2004 (B5 Series)
VOLKSWAGEN PASSAT 2005 - 2014 (B6 - B7 Series)
VOLKSWAGEN POLO 2005 - 2009 (6Q - 9N - 9N3 Series)
VOLKSWAGEN POLO 2010 - 2014 (6R Series)
VOLKSWAGEN TIGUAN 2007 - 2016 (5N Series)
VOLKSWAGEN TOUAREG 2004 - 2010 (7L)
VOLKSWAGEN TRANSPORTER (Incl MULTIVAN or CARAVELLE) 2015 - 2019 (T6 Series)
VOLVO S60 2001 - 2009 (1st Generation)
VOLVO S80 1998 - 2006 (1st Generation)
VOLVO V70 2000 - 2004 (2nd Generation)
VOLVO XC70 2003 - 2007 (2nd Generation)
VOLVO XC90 2002 - 2014 (1st Generation)
SKU PACSWICP5
Barcode # 609098813860
Brand Pac Audio
Shipping Weight 1.5000kg
