- Designed for recess mounting.
- Concealed mounting holes.
- Door opens past 180°.
- 10mm clearance from start of flange to beginning of screw hole.
- 316G stainless steel hinge.
- OEM can screw through the hinge into the deck for added strength and durability.
- In-laid gasket ensures a good seal every time.
- Saralon 2 resin Handles with a positive stop and click
- secured by a 316G stainless steel pin.
- Injection moulded tubs for a lifetime of use.
- UV resistant.
- Made in USA.
- 38262/38263 2 Plano 3600 Series Tackle Inserts.
- 38280/38281 3 Plano 3600 Series Tackle Inserts.
- 38264/38265 3 Plano 3700 Series + 1 Plano 3600 Series Tackle Inserts.
Part No. | 38263 |
Cut Out | 160mm x 325mm |
Corner Radius | 25mm |
Mount Screws | 4mm c/s |
Colour | Black |
Draws | 2 |
Overall Size (H x W x D) | 204mm x 369mm x 229mm |
SKU | 38263 |
---|---|
Barcode # | 9330420182682 |
Brand | Plano |
Shipping Weight | 1.5000kg |
