The VA02-BP70/LL-52A (EF3636) 24v 9" SPAL Puller Fan features a Skew (curved) Blade Design which can pull up to 785cfm / 1330m3/h.
Individually balanced for long life, the EF3636 9" Puller Fan features a fully sealed water & dust-proof motor of superior quality and backed with a 3-year manufacturers .
| EF3636 9" SPAL THERMO FAN DETAILS | |
|---|---|
| SPAL Fan Model # | VA02-BP70/LL-52A |
| U.S. Part # | 30102592 |
| Voltage | 24V |
| Flow Type | Puller |
| Blade Diam. | 9 inch (225mm) |
| Blade Type | Skew |
| Shroud Type | Open Shroud |
| Amps | 4.5 |
| CFM | 785 |
| M3/H | 1330 |
| Spec. Sheet | View Specifications  |
| EF3636 9" SPAL THERMO FAN DIMENSIONS | |
|---|---|
| A | 237.8mm / 9.36" |
| B | 206.4mm / 8.13" |
| C | 139.2mm / 5.48" |
| D | 247.5mm / 9.74" |
| E | 95.4mm / 3.75" |
 |
|
| ABOUT SPAL |
|---|
|
All SPAL Fans are individually balanced & tested to provide optimal performance and life. From the motor to the fan to the shroud, all components are completely designed, manufactured and tested in SPAL's state-of-the-art facility in Correggio, Italy. href=" ?filter.p.tag=SPAL+Accessory" title=" More">
 |
Designed to withstand the harshest environments, SPAL fans are unmatched in quality and reputation.
| SKU | EF3636 |
|---|---|
| Barcode # | 9316042298413 |
| Brand | SPAL |
| Shipping Weight | 5.0000kg |
| Shipping Width | 0.095m |
| Shipping Height | 0.206m |
| Shipping Length | 0.238m |
SPAL Thermo Puller Fan - 9" - 24V - 785 CFM - VA02-BP70/LL-52A
