Description
LED Bar Light 22" DCX2 Series Curved Combo Beam 10-30V 40 x 3W Osram High Lux LEDs 120W 10800lm IP67 Slide & End Mounts Roadvision Black Label
The Roadvision DCX2 Series are the next generation in dual row curved LED light bars. Producing up to a massive 25920lm of light output, the DCX2 Series
deliver brute power and intense light output with a perfect match of advanced optical design and 3W Osram Hi-Lux LEDs. Designed to follow the contour of
your vehicle, the curved designed provides greater illuminating coverage, giving you a better field of view in any open road or off road situation. Featuring the
latest soft start, PWM dimming and advanced thermal management technology from Roadvision, the DCX2 Series is available in combination beam patterns
from 22” to 50” providing a perfect mix of forward penetration and additional roadside illumination from the curved radius housing. Supplied with both low
profile adjustable slide mounts and Roadvision’s new 9 position adjustable anti-vibration mounting system, the DCX2 Series also features a new ultra slim
65mm deep housing providing greater mounting flexibility. The DCX2 Series by Roadvision, brute power from the biggest bars in our line-up.
Product features:
- DCX2 Series dual row curved LED bar lamps produce up to 25920lm of light
- 3W Osram Hi-Lux LED’s produce super white light close to daylight
- Curved bar produces a wider beam angle for improved roadside illumination
- Multi-volt 10-30V DC input & super low current draw
- 50,000 hour LED lifespan with solid state technology
- Soft start, PWM dimmable & advanced thermal management technology
- Light weight tough die-cast aluminium housing & polycarbonate lens
- Water & dust proof IP67 rated
- Simple 2 wire installation Deutsch/ATP plug & optional plug & play dimming controller
- 9 position adjustable anti-vibration end mount system & low profile slide mounts
- Over/under voltage, reverse polarity protection & EMI/EMC radio interference approved
Product specifications:
- Wiring 2 Pin Deutsch Plug
- Warranty 7 years
- Input Voltage 10-30V DC
- LUMENS 10800Lm
- Total Watts 120W
- Beam Pattern Combination
- Beam Distance 354m @ 1 Lux
- Mounting Slide & End Mounts
- Weight 3.5kg
- Brand Roadvision
- LED's 40 Leds 3w Osram
- Current Draw 6.7 Amps @ 13.8V
- IP Rating IP67
- Unit Dimensions 563x75x78.5mm
- Total Dimensions 70x15x17cm
Specifications
| SKU | RBL6220C |
|---|---|
| Barcode # | 9340330020868 |
| Brand | Roadvision |
| Shipping Weight | 3.0000kg |
Roadvision LED Bar Light 22 DCX2 Series Curved Combo Beam 10-30V 40 x 3W Osram High Lux LEDs 120W 10800lm IP67 Slide & End Mounts Roadvision Black La"
SKU: RBL6220C
More infoMake 4 payments of $86.50 over 8 weeks and get it now!
This 22" DCX2 Series Curved Combination Beam LED Bar Light is the next generation of dual row LED Light Bars, with up to an intense 10800ml light output and including the slide and end mounts.
