This REDARC 24V 20A In-vehicle dual input DC to DC battery charger designed to keep your battery charged whilst driving, featuring an MPPT solar regulator to boost power supply from solar.The 20A In-Vehicle DC-DC REDARC Battery Charger is designed to keep any commonly used 24-volt battery system charged to an optimal level using battery charging algorithms that takes the chemistry of your battery into account. If you have solar panels installed, it can also use that power supply to keep your battery charged even when you're parked. Multi-stage DC to DC charging keeps your auxiliary battery charged at the optimum level, plus it can act as a dual battery isolator to protect your starter battery when the voltage drops below appropriate levels. This REDARC 24V 20A battery charger and isolator is suited for use with 12V and 24V systems, meaning it can be powered by 12v solar panels. The MPPT Solar charging algorithm extracts the maximum available power from your solar panels at any given time.

The Smart Charger is compact, easy to install, and completely sealed to keep it protected from water, dust, and vibration. Its protections make it a great fit for any driver - even those who enjoy taking to Australia's harshest conditions, like outback tracks and deep water crossings. It's even hardy enough for marine applications! The Charger will act as a dual-battery isolator to help protect the start the battery whenever its voltage level gets too low. The REDARC Smart Battery Charger is delivered with a 2-year manufacturer's warranty covering faults and material defects.

*Mounting brackets sold seperately.*

Features

• Multi-Stage DC to DC Battery Charger
• MPPT Solar Regulator
• Start Battery Isolator
• Fully sealed
• No fan for super-quiet operation
• Charges AGM, Gel, Calcium content, VRLA and Standard Lead Acid batteries

Product Specifications:

• Input (Operating) Voltage: 9 - 32VDC
• Maximum Charging Voltage: 30.6V
• Output Current Rating (Cont.): 20A
• Input Current (Max.): 40A
• Input Fuse Rating: 50A
• Output Fuse Rating: 30A
• Standby Current Draw: <50mA
• Output System Voltage: 24VDC
• Output Power: 600W
• Length (mm): 150
• Width (mm): 120
• Height (mm): 37
• Weight (kg): 0.68
• Type Approval: E and CE
