Suitable For Amplified Models
Retain your factory amplifier when upgrading your factory radio/infotainment with your new head unit.
Suitable for GM vehicles with the standard or premium amplified system.
Retain Control
When used with the Autoleads CP2-UNI or PAC SWI-CP2 interface (NOT INCLUDED), audio steering wheel control buttons can be retained with select major branded aftermarket infotainment systems in select vehicles.
(NOT INCLUDED WITH RP3GM11. AVAILABLE SEPARATELY)
Supports brands including
- Alpine
- Clarion
- JVC
- Kenwood
- Pioneer
- Stinger
- Sony
Plug & Play
With the included multi-connector harness, no modification to your vehicle harness is required.
Simply attach your new infotainment/head unit harness onto the supplied harness with the RadioPRO3 kit and plug in.
Includes Everything You Need
The kit includes
- Amplifier Retention Interface
- Plug-n-play harnesses
FEATURES
- High current 10A accessory output
- Data controlled outputs for connection to your navigation radio; speed, reverse and E-brake status output wires
- Retains factory installed amplifier (standard & premium)
- Data controlled RAP accessory output
- Keeps vehicle data bus intact for service
- Plug-in-connection for steering wheel control module (SWI-RC, SWI-RC-1 or SWI-CP2)
- In package updatable using the PAC-UP
- Adjustable chime volume: 4 levels, and off
| Retain Factory Amplifier? | YES |
|---|---|
| Plug & Play | YES – FACTORY CONNECTOR TO BARE WIRES |
| Retain Factory Steering Wheel Audio Controls? | NO – However you will require a CP2-UNI or PACSWICP5 to retain Steering wheel audio buttons |
| Vehicle Make | Vehicle Model | Vehicle Year + Vehicle Chassis Code |
|---|---|---|
| CHEVROLET | AVALANCHE | 2003 - 2006 (SECOND GEN) |
| CHEVROLET | SILVERADO | 1999 - 2006 (FIRST GEN) |
| GMC | SIERRA | 1999 - 2006 (FIRST GEN) |
| GMC | YUKON | 2007 - 2014 (GMT900 (3RD GEN)) |
| HUMMER | H2 | 2002 - 2007 (H2) |
| HUMMER | H3 | 2006 - 2011 (H3) |
| SKU | PACRP3GM11 |
|---|---|
| Barcode # | 606523109376 |
| Brand | Pac Audio |
| Shipping Weight | 1.5000kg |
Radio Pro 3 Gm Lan Class 2 - 24 Pin Interface
