Quad Shunt Mod 4 X 50A Input Current & 1 X Relay Output 1A

Description
Specifications

Description

Features

SCQ50 is an innovative shunt module for monitoring individual consumers and generators with;

4 x 50A Current Sensors
For 12v and 24v Systems

Connection Possibilities;

Up To 4 x Consumer Devices
Up To 4 x Generators
Combination of 4 of both
1 x Relay Input

Free SIMARINE Android and iOS Apps:

Simarine offers a free App to connect your PICO display to your smartphone via Wi-Fi. The Apps allow you to monitor all battery and tank data, upload history, edit and restore settings and even upgrade the firmware with new features.

Specifications

Model	Simarine Quadro Shunt Module
SI-SCQ50	Quad Shunt 4 x 50A Circuits Module
Operating
Power Source Voltage Range	6-35V
Temperature Range	-20 - +70°C
Power Consumption at 12V
Operating	3.5mA
Current Measuring Channels	4
Relay (monostable)
Maximum Operating Current	1A
Maximum Common Input Voltage	6 – 30V
Voltage Inputs
Per Channel	0.01 – 50A
Resolution	0.01A
Accuracy	± 0.6 %
Sampling Rate	100ms
Maximum Currents
Continuous	50A
Peak Current (<1 min)	60A
Peak Current (<5 sec)	60A
Voltage Drop at 25 A	35mV
Maximum voltage on connections	35V
Connectivity	Up To
Current Sensors	4
Relay Common Input (COM)	1
Relay Output Normally Open (NO)	1
Relay Output Normally Closed (NC)	1
SiCOM RJ9 Sockets	2
Installation and Dimension
Dimensions (length x width x depth)	182 x 80 x 37 mm
Weight	230g

Specifications

SKU	SI-SCQ50
Barcode #	SI-SCQ50
Brand	Enerdrive
Shipping Weight	0.5000kg
Assembled Length	0.150m
Assembled Height	0.100m
Assembled Width	0.150m

$339.00

SAVE $40.00

DON'T PAY RRP $379.00
