The PAC AmpPRO AP4-TY13.R2 provides a 6-channel RCA output from the factory infotainment system for use with aftermarket audio equipment including Aftermarket Amplifiers and Digital Sound Processors.
Designed for SELECT Toyota Vehicles
Aftermarket Amplifier Integration Made Easy
Many of today's vehicles have fancy radios with lots of features, Bluetooth, vehicle settings, climate control, amplified audio systems and more.
When you want to get better quality sound and more power, adding an amplifier is great way to improve your audio system.
This can be difficult and time consuming on a-lot of vehicles.
PAC simplifies this with AmpPRO, the plug and play amplifier integration solution.
Compatible With Nearly Every Aftermarket Amplifier
Featuring 6 channels of RCA output, the AmpPRO interface is designed to be used with many aftermarket amplifiers offering front, rear and sub-woofer outputs.
As long as your aftermarket amplifier has RCA inputs, your set to go
Plug and Play With Ease
Each AmpPRO interface includes a vehicle specific Plug and Play harness. This harness saves time having to hard-wire in like conventional line out converters and also offers the ability to retain extra factory audio channels like Bluetooth and navigation audio.
Plugs into the OEM Radio at the dash board and away you go.
With the supplied bass control knob, you can directly adjust the volume of the sub-woofer channels even if your factory radio didn't have it.
Digital Expandability
Installing a digital sound processor or a high end amplifier with TOSlink Input?
With the optional APA-TOS1 interface (sold separately) you can feed a digital stereo signal straight to your amplifier or DSP for the best quality sound.
(Fading control not possible with using Toslink output)
Complete Control At Your Fingertips
Most modern vehicles have extensive data control networks like CANBUS. The AmpPRO Interface is designed to communicate with these networks giving you complete control from your factory infotainment system like from factory including
- Bass
- Treble
- Fading
- Balance
You even get a 3 Band adjustable EQ (via PAC AmpPRO Application for Windows) where you can adjust
- Frequency
- Q Factor
- Gain
- Warning Chime Levels (vehicle dependant)
Includes Everything You Need
The PAC AmpPRO AP4-TY13.R2 kit includes
- Vehicle Specific Interface with RCA Pre-Outs
- Vehicle Specific 'T' Harness
- Subwoofer (CH5+6) Level Controller port,
- Subwoofer Level Controller Harness
- Instruction Manual
Compatibility Notes
- Lexus ES250, ES350, and NX300: Only compatible in models equipped with the 8" screen
- Lexus RX350 and RX450: Not compatible in models equipped with navigation
- In 2018+ models Toyota used three different styles of connectors on the factory radios. In order for the AP4-TY13 to be compatible, the radio must have the 28 / 10-pin new Toyota style connector. Vehicles equipped with the 20-pin BHA8113 or the 10 / 6 pin BHA1761 style connectors are not compatible. The only way to know what connector the radio has is to physically remove it from the dash and look at it. Please see pictures below for reference.
Product Overview Video
| Plug & Play | YES |
|---|---|
| Vehicle Plug Style | 28PIN + 10PIN Connectors |
| RCA Pre-Outs | 6 Channel Stereo |
| Optical Audio Out | Requires PACAPA-TOS1 module to offer 1x TOSLINK Audio Output |
| Vehicle Make | Vehicle Model | Vehicle Year + Vehicle Chassis Code |
|---|---|---|
| LEXUS | ES | 2019 - 2021 (XV70) |
| LEXUS | NX | 2019 - 2021 (AZ20) |
| LEXUS | RX | 2019 - 2021 (GGL25R) |
| TOYOTA | CAMRY | 2018 - 2020 (XV70 Series) |
| TOYOTA | COROLLA HATCH | 2019 - 2021 (E210 Series) |
| TOYOTA | RAV4 | 2019 - 2022 (XA50 Series) |
| TOYOTA | RAV4 | 2019 - 2022 (XA50 Series) WITH 360 DEGREE CAMERA SYSTEM |
| SKU | PACAP4-TY13.R2 |
|---|---|
| Barcode # | 609098828291 |
| Brand | Pac Audio |
| Shipping Weight | 1.5000kg |
