Remote on-off connector- The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch (see manual).
All models with adjustable output can also be used as a battery charger- For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.
All models with adjustable output can be paralleled to increase output current- Up to five units can be connected in parallel.
The Orion 12/27,6-12: a 24V battery charger (see page 2)- To charge a 24V battery from a 12V system. The output voltage of this model can be adjusted with a potentiometer
A super wide input range buck-boost regulator: the Orion 7-35/12-3 (see page 2)- The Orion 7-35/12-3 is an isolated converter with a very wide input range, suitable for both 12V and 24V systems, and a fixed 12,6V output.
Easy to install- Delivery includes four Insulated Fastons Female Crimp 6.3mm (eight Fastons in case of the Orion 24/12-40).
|
Non isolated converters |
Orion 24/12-25 |
Orion 24/12-40 |
Orion 24/12-70 |
Orion 12/24-8 |
Orion 12/24-10 |
Orion 12/24-20 |
|
Input voltage range (V) |
18-35 |
18-35 |
18-35 |
9-18 |
9-18 |
9-18 |
|
Under voltage shutdown (V) |
14 |
14 |
14 |
8 |
8 |
8 |
|
Under voltage restart (V) |
18 |
18 |
18 |
10 |
10 |
10 |
|
Output voltage adjustable with potentiometer |
yes |
no |
yes |
no |
yes |
yes |
|
Output voltage (V) |
Adjustable 10–15V F set 13,2V |
13,2 |
Adjustable 10–15V F set 13,2V |
24 |
Adjustable 20-30V F set 26,4V |
Adjustable 20-30V F set 26,4V |
|
Efficiency (%) |
96 |
95 |
92 |
95 |
95 |
93 |
|
Suitable to buffer-charge a battery |
yes |
no |
yes |
no |
yes |
yes |
|
Can be connected in parallel |
yes |
no |
yes |
no |
yes |
yes |
|
Continuous output current (A) |
25 |
40 |
70 |
8 |
10 |
20 |
|
Max. Output current (A) |
35 |
55 |
85 |
20 |
20 |
30 |
|
Fan assisted cooling (temp. controlled) |
no |
yes |
yes |
no |
no |
yes |
|
Galvanic isolation |
no |
no |
no |
no |
no |
no |
|
Off load current |
< 15mA |
< 20mA |
< 20mA |
< 10mA |
< 15mA |
< 30mA |
|
Remote on-off |
yes |
yes |
yes |
no |
no |
yes |
|
Operating temperature range (derate 3% per °C above40°C) |
-20 to +55°C |
-20 to +55°C |
-20 to +55°C |
-20 to +55°C |
-20 to +55°C |
-20 to +55°C |
|
DC connection |
Faston tabs 6.3 mm |
Double Faston tabs 6.3 mm |
M6 bolts |
Faston tabs 6.3 mm |
Faston tabs 6.3 mm |
M6 bolts |
|
Weightkg (lbs) |
0,7 (1.55) |
0,85 (1.9) |
0,9 (2.0) |
0,4 (0.8) |
0,4 (0.9) |
0,9 (2.0) |
|
Dimensions hxwxd in mm (hxwxd in inches) |
65x88x160 (2.6x3.5x6.3) |
65x88x185 (2.6x3.5x7.3) |
65x88x195 (2.6x3.5x7.7) |
45x90x115 (1.8x3.5x4.5) |
45x90x125 (1.8x3.5x4,5) |
65x88x195 (2.6x3.5x7.7) |
|
Standards: Safety Emission Immunity Automotive Directive |
EN 60950 EN 61000-6-3, EN 55014-1 EN 61000-6-2, EN 61000-6-1, EN 55014-2 ECE R10-4 |
|||||
| SKU | ORI122410020 |
|---|---|
| Barcode # | 8719076022749 |
| Brand | Victron |
| Shipping Weight | 0.9000kg |
More infoMake 4 payments of $32.00 over 8 weeks and get it now!
