Specifications
General specifications | ||
Nominal output voltage | 24 V | |
Total charge current | 100 A at 28,5 V | |
Number of battery outlets | 1 | |
Battery bank size | 200-1000 Ah | |
Nominal input voltage | 230 V (180-265 V), 50/60 Hz | |
Power supply mode | yes | |
Galvanic isolation | yes | |
Display/read-out | LED display | |
Dimensions, hxwxd | 420 x 318 x 130 mm 16.5 x 12.5 x 5.1 inch |
|
Weight | 7.7 kg 17.0 lb |
|
Compliance | CE, ABYC A-31, RRR, RMRS, DNV GL | |
Technical specifications | ||
Charge characteristic | IUoUo, automatic 3-step+ for Gel/AGM/wet/Lithium Ion | |
Charge voltage Bulk | 28.5 V | |
Charge voltage Absorption | 28.5 V | |
Absorption time | 4 hours | |
Charge voltage Float (wet batteries) | 26.5 V | |
Charge voltage Float (Gel/AGM batteries) | 27.6 V | |
Temperature sensor | yes (included) | |
DC voltage compensation | yes | |
Power consumption (DC side) | < 1 mA | |
Full load consumption (230 V AC) | 3500 W | |
Current Control function | yes, through MasterBus | |
Power factor control | > 0.95 | |
Temperature range (ambient temp.) | -25 °C to 80 °C, derating > 40 °C -13 °F to 176 °F |
|
Cooling | vario fan | |
Protection degree | IP23 | |
Protections | over temperature, over load, short circuit, high/low battery voltage | |
MasterBus compatible | yes | |
Charger Status Interface (alarm contact) | yes | |
SKU | MV-40021006 |
---|---|
Barcode # | OEBC537876 |
Brand | Mastervolt |
Shipping Weight | 7.9000kg |
Shipping Width | 0.150m |
Shipping Height | 0.420m |
Shipping Length | 0.320m |
