Specifications
Communication & monitoring | ||
Communication interfaces | MasterBus, CZone, NMEA 2000 | |
General specifications | ||
Nominal output voltage | 24 V | |
Secondary output voltage | 14.25 /28.5 V (12/24 V) | |
Max. output current primary output | 110 A | |
Max. output current secondary output | 5-15 A at 12 V / 5-20 A at 24 V (adjustable) | |
Total charge current | 110 A at 28.8 V | |
Max. AC current (230 V / 120 V) | 15.75 A / 31.5 A | |
Number of battery outlets | 2 (max.) | |
Battery bank size | 400-1000 Ah | |
Nominal input voltage | 120/230 V (80-275 V) 50/60 Hz | |
AC connection | screw terminals, suitable up to up to 6 mm² | |
Power supply mode | yes | |
Galvanic isolation | yes | |
Display/read-out | LED | |
Dimensions, hxwxd | 384 x 250 x 127 mm 15.1 x 9.8 x 5.0 inch |
|
Weight | 6.3 kg 13.9 lb |
|
Compliance | CE, ABYC, UL1236, SAE J1171, ISO 8846, CEC/DOE, RCM/C-Tick, RRR | |
Technical specifications | ||
Charge characteristic | IUoUo, automatic / 3-step+ for Gel/AGM/flooded/Lithium Ion + user defined option | |
Temperature compensation | -60 mV/°C / -76 mV/°F; incl. temperature sensor | |
DC voltage compensation | through automatic compensation or MasterShunt | |
Power consumption (DC side) | < 2 mA (MasterBus off) | |
Current Control function | yes, through MasterBus or CZone | |
Power factor control | yes, > 0.98 | |
Temperature range (ambient temp.) | -25 °C to 80 °C, derating > 40 °C -13 °F to 176 °F |
|
Cooling | vario fan | |
Protection degree | IP23, vertical mounting | |
Protections | over-temperature, overload, short circuit, high/low battery voltage, ignition protection | |
Charger Status Interface (alarm contact) | yes, using a Multipurpose Contact Output (code 77030500) | |
SKU | MV-44321105 |
---|---|
Barcode # | OEBC537878 |
Brand | Mastervolt |
Shipping Weight | 6.5000kg |
Shipping Width | 0.150m |
Shipping Height | 0.390m |
Shipping Length | 0.270m |
