Ignite 4.9" Square LED Worklamp 9 - 36 Volt 43.2 Watt
Integrated Electronic Thermal Management (ETM)
Black Anondised Polyester Powder Coated Die-Cast Aluminium Alloy Housing with integrated
6063 Extruded Aluminium Heat-Sink
Stainless Steel Single Bolt Rubber dampened Mounting Bracket and Stainless Steel Mounting Hardware
In-Built 2 Pin Deutsch Plug in back of housing
Over and Under Voltage Protection
Reverse Polarity Protection
50° Flood (Spread) Beam Pattern
UV, Water and Shock resistant
50,000 Hours LED Lifespan
ECE R10, CE Approved and EMC Compliant, CISPR 25 Class 5 Certified
IP68 and IP69K Rating
Environment Temperature: -40°C ~ +60°C
5 Year Warranty
4,150 Effective Lumens, 5,400 Raw Lumens and 6,500K
36 x 1.2 Watt High Intensity Lumileds LED's
3.6amps @ 12 Volt and 1.6amps @ 24 Volt Current Draw
Patented Multi-Surface Polycarbonate TIR Optical System Reflector Technology with Polycarbonate Lens
Light Transmittance >95%
Beam Type | Flood |
Depth (mm) | 65 |
Height (mm) | 143 |
Mount | Single Bolt |
No. of LED | 36 |
Series | Other |
Shape | Square |
Type | LED |
Voltage | Multivolt |
Watts | Other |
Width (mm) | 122 |
SKU | IWL410F2 |
Barcode # | 9323327943227 |
Brand | Ignite |
SKU | IWL410F2 |
---|---|
Barcode # | 9323327943227 |
Brand | Ignite |
Shipping Weight | 1.0000kg |
