Humminbird Helix 5 Fishfinder G2 With Transducer (No Maps)

SwitchFire Sonar: Take command of how your sonar returns appear. With two display modes, you can add or remove detail, account for water depth, temperature and turbulence, even watch lure presentations – all at the push of a button.
Dual Beam PLUS Sonar: Two beams combine for great detail and a generous coverage area, helping you identify fish, structure and contours. Use the narrow beam for high-accuracy returns of fish, structure, detail and the bottom profile. Opt for the wide beam when you want a larger search area. You can view the beams separately, side-by-side or blended together for the complete picture. Your coverage area will be equal to your depth.

Item Number	104450
Series	HELIX
Display Size – Diagonal	5″
Display Pixel Matrix	800H x 480V
Sonar-Standard	DualBeam PLUS
Sonar-Coverage	20° & 60° @ -10dB
Sonar-Frequencies Supported	83/200 kHz
Depth-Sonar	1,500 ft (standard transducer)
Interface	Keypad Control
Memory Card Slot	None
Compatible With	AIS, AutoPilot
Power Draw	650 mA
Power Input	10.8-20 VDC
Power Output Peak-to-Peak	4000 Watts
Power Output RMS	500 Watts
Screen Snap Shot	Not Supported
Sonar Recording	Not Supported
Mount-Standard	Gimbal
Mount-Standard Size	7.55″ W x 4.64″ H x 3.3″ D
Mount-Optional Size	7.55″ W x 4.28″ H x 1.13″ D
Transducer Mount Location	Transom
GPS Chartplotting	Not Supported
GPS Trackplotting	Not Supported
LakeMaster Compatibility	No
Coast Master Compatibility	No
Navionics Gold/HotMaps Compatibility	No
Navionics Platinum + Compatibility	No
Platinum Compatibility	No
Heading Sensor GPS Compatibility	No
Upgradable Software	Yes
View Preset Keys	Yes
X-Press Menu System	Yes
Custom Digital Readout	Yes
Custom View Selections	Yes
Display Colors Grayscale	16-Bit
Display Size	5″ – 7″
Speed	Optional
Temperature	Built In
Temperature Alarm	Yes
Temperature Graph	No
Transducer Included	XNT 9 20 T

$549.00
