FEATURES |
• Provides unsurpassed fuel filtration and water separation, and is comparable to the Racor Marine 1000 series filters. • The GTB681 series filter use GRIFFIN replacement element GTB68, formerly designated as G2020, in 3 micron sizes, 2, 10, & 30. • Comes standard with a 10 micron GRIFFIN MICROBLOC element. • Heat Deflector Shield: PHDS36MA. • Hose fittings are sold separately. |
Part No. | 374130 |
Weight | 2.9kg |
Dimensions | H 535mm x W 147mm x D 165mm |
Temperature | -20°C / +121°C |
Clean Pressure Drop | 3.3kPa |
Max. Operating Pressure | 103kPa |
Cross Ref. | 1000MA / G1000S4MA |
Micron Elements | 374134 / 374135 / 374136 |
Clear Bowl for Gasoline Use | 374138 |
Fuel Port | 7/8-14 inch UNF |
Flow Rate | 681LPH (180GPH) |
Service Clearance | 254mm |
SKU | 374130 |
---|---|
Barcode # | 9330420091410 |
Brand | Griffin |
Shipping Weight | 2.9000kg |
