Features
- Made from marine grade anodised aluminium giving long life, excellent corrosion resistance, durability and low maintenance requirements
- All GEBO hatches are CE class-A ocean certified
- 2 year warranty under normal use
- 40mm height above deck. Silicone rubber seals
- 2 styles - Internal flange 5mm deep - or NO flange style
- Durable 10mm to 15mm thick smoked grey acrylic panels
- Heavy duty no-snag adjustable friction hinges hold the hatch open in any position up to 180 deg, including a fully locked ventilation position
- Not a single catch, lip or knob for sails or rope lines to get caught on
- Inside / outside opening handles with sturdy blue locking button
- All hinges and metal parts are made from non-corrosive materials
- Mosquito/fly screens, inner dress rims and spare parts available
- Hatches WITHOUT flange have a 30mm cut-out radius (except 6033)
NB: Category A – Ocean: covers largely self-sufficient boats designed for extended voyages with winds of over Beaufort Force 8 (over 40 knots), and significant wave heights above 13 feet, but excluding abnormal conditions such as hurricanes.
Specifications
SKU | Cutout Size mm | Cutout Radius | Overall Size mm | Acrylic Thickness | Mosquito Screen | Inner Rim Alum. | Fly-Bind Combo |
RWB6020 | 200 x 200 | 30mm | 260 x 260 | 10mm | RWB6130 | RWB6205 | |
RWB6021 | 260 x 260 | 30mm | 320 x 320 | 10mm | RWB6131 | RWB6206 | |
RWB6022 | 325 x 185 | 30mm | 385 x 245 | 10mm | RWB6132 | RWB6207 | |
RWB6023 | 341 x 196 | 30mm | 401 x 256 | 10mm | RWB6133 | RWB6208 | |
RWB6024 | 410 x 410 | 30mm | 470 x 470 | 10mm | RWB6134 | RWB6209 | |
RWB6025 | 450 x 320 | 30mm | 510 x 380 | 10mm | RWB6135 | RWB6210 | RWB6100 |
RWB6026 | 451 x 451 | 30mm | 511 x 511 | 10mm | RWB6136 | ||
RWB6027 | 500 x 370 | 30mm | 560 x 430 | 10mm | RWB6137 | RWB6211 | RWB6101 |
RWB6028 | 500 x 500 | 30mm | 560 x 560 | 10mm | RWB6138 | RWB6212 | RWB6102 |
RWB6029 | 620 x 620 | 30mm | 680 x 680 | 15mm | RWB6139 | RWB6213 | RWB6103 |
RWB6030 | 800 x 800 | 30mm | 860 x 860 | 15mm | RWB6140 | RWB6214 | |
RWB6031 | 900 x 900 | 30mm | 960 x 960 | 15mm |
SKU | RWB6022 |
---|---|
Barcode # | 9324608030605 |
Brand | Gebo |
Shipping Weight | 3.0000kg |
