Features / Specifications

• Various Flash Pattern 180˚
• 12 Strobe Function Synchronised
• Available in 5 Colours
• IP67 100% Water proof
• Voltage Range 12-24 Volt
• 112mm x 37mm x 23mm


Download Data Sheet

Fitting Instructions

Fix to flat surface at two fixing points.

Wire Colour & Flash Pattern Selection

• Red - Power
• Black - Earth
• White - Low Power [Connect white wire to black wire for low power, strobe functions only]
• Yellow - Synchronising (Optional) [1 sec next pattern] [1-3 sec previous] [3-5 sec steady] [5 sec + off]. Connect yellow wires of all lamps together for synchronisation.

Technical Drawings
