Audi Radio Replacement Interface
Make installation of your new aftermarket radio or infotainment system easy in select Audi
vehicles with the Plug & Play ConnectPRO Audi radio replacement solution from Stinger Australia
The Radio Replacement Solution
There's nothing worse than loosing your steering wheel control buttons when updating to the latest technology.
The SWI-VW01 from ConnectPRO from Stinger Australia allows easy retention of steering wheel audio control buttons plus even your factory amplifier (if fitted – see notes) with your new aftermarket radio or infotainment system.
Keep your eyes on the road and less time fumbling for the radio with ConnectPRO.
The Solid Connection
Each ConnectPRO radio replacement solution includes a Plug and Play interface for a easy and solid connection to your existing vehicle harness.
No need to strip back wires or chop off connectors in your vehicle allowing re-installation of your factory radio if ever required.
Feature Packed
The ConnectPRO SWI-VW01 features:
- Retains factory fitted steering wheel audio buttons
- Retains factory fitted amplifier (SEE NOTES)
Suitable for vehicles with
- 40PIN Quadlock
- Mini ISO Connections
What Do You Get?
The ConnectPRO SWI-VW01 kit includes
- Autoleads ControlPRO.2 CP2-UNI.2 Interface
- 40 Pin Quadlock Vehicle Plug and Play Harness
- 'Mini ISO' Vehicle Plug and Play Harness
- CP2-UNI.2 Bare wire harness
- Instruction Manual
Compatibility Notes
- Vehicles with Digital Amplified System cannot be retained.
Amplifier must be bypassed
- Factory Reverse Camera Not Retained (if fitted)
- Phone buttons cannot be retained in all vehicle models (if fitted)
- Voice Recognition (VR) Button feature not retained (if fitted)
- Multimedia Outputs (Reverse / Handbrake / VSS / Illumination) only available if data is present on vehicle network
- Designed for use with major branded head units including
Alpine, Clarion, Kenwood, JVC, Pioneer, Sony, Stinger plus more
| Plug & Play | YES – FACTORY CONNECTOR TO STANDARD ISO CONNECTOR |
|---|---|
| Retain Factory Steering Wheel Audio Controls? | YES – Will retain Steering Wheel Audio Controls with Select Aftermarket Radios |
| Retain Factory Amplifier? | YES – Base Model Amplifiers ONLY. Not compatible with Digital OEM Amplifier |
| Vehicle Plug Style | 40PIN Quadlock Style Connector, Standard Mini ISO Connector |
| Vehicle Make | Vehicle Model | Vehicle Year + Vehicle Chassis Code |
|---|---|---|
| AUDI | A3 (Incl S3) | 2004 - 2013 (8P) |
| AUDI | A4 (Incl S4) | 2001 - 2008 (B6-B7) |
| AUDI | A4 (Incl S4) | 2009 - 2015 (B8) |
| AUDI | A6 (Incl S6) | 2005 - 2011 (4F) |
| AUDI | TT | 2006 - 2014 (8J) |
| SKU | SWI-VW01 |
|---|---|
| Barcode # | 9342270006643 |
| Brand | ConnectPRO |
| Shipping Weight | 1.5000kg |
Connectpro Swc Interface - Audi Can-Bus Quadlock & Mini Iso
