82 Series with Resistors and DT Plug
82 Series w Resistors / DT Plug
Features / Specifications
NOTE: When using load resistors in a vehicle that has lamp failure monitoring, failure of the lamp will not be detected.
|
Fitting InstructionsHorizontally mount bracket onto flat surface with screws provided, ensuring TOP markings are positioned above centre holes. Remove backing from 3M tape on back of lens, run wires through desired centre hole and align the locator nodule on edge of lens with the corresponding indentation on bracket. Apply firm hand pressure to ensure lamp adhesion. Repeat for each lens until all are installed securely. Load resistors must be mounted on metal surface, the module can reach temperatures of up to 170 Celsius. Technical Drawings |
SKU | SO82BARWCC2LR12 |
---|---|
Barcode # | 9335962103447 |
Brand | LED Autolamps |
Shipping Weight | 0.5200kg |
Shipping Width | 1.118m |
Shipping Height | 0.365m |
Shipping Length | 0.055m |
82 Series with Resistors and DT Plug
82 Series w Resistors / DT Plug
Features / Specifications
NOTE: When using load resistors in a vehicle that has lamp failure monitoring, failure of the lamp will not be detected.
|
Fitting InstructionsHorizontally mount bracket onto flat surface with screws provided, ensuring TOP markings are positioned above centre holes. Remove backing from 3M tape on back of lens, run wires through desired centre hole and align the locator nodule on edge of lens with the corresponding indentation on bracket. Apply firm hand pressure to ensure lamp adhesion. Repeat for each lens until all are installed securely. Load resistors must be mounted on metal surface, the module can reach temperatures of up to 170 Celsius. Technical Drawings |
SKU | SO82BARWCC2LR12 |
---|---|
Barcode # | 9335962103447 |
Brand | LED Autolamps |
Shipping Weight | 0.5200kg |
Shipping Width | 1.118m |
Shipping Height | 0.365m |
Shipping Length | 0.055m |
