Features:

• Front terminals make installation, maintainance and supervision easy
• Shield design protects terminals from short circuit
• Unique vent valve design, reducing water loss and prevent air/spark from entering
• 26 month warranty

Specifications:

• Nominal volage 12v
• Nominal capacity 120Ah @ 20 hour rate FV (1.8V/cell)
• Approximate weight 31.0kg (68.34lbs)
• Terminals 13 (M8 female thread)
• Internal resistance ? 3.5 ? (fully charged)
• Maximum discharge current 1200A (5 sec)
• Maximum charge current 25A
• Operating temperature range
• Charge: -10C~40C (14F~104F)
• Discharge: -20C~50C (4F~122F)
• Storage: -15C~40C (5F~104F)
• Self discharge 3% of capacity declined per monthat 25C
• Dimensions battery 395mmL x 110mmW x 285mmH
• Dimensions terminal 16mm dia x 6mmH x 8mm hole dia
