Features
- Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing
- LED output to remotely indicate switch state – requires optional LED
- ML-Series Remote Control Contura Switch PN 2145 available as a seperate item.
- 3∕ 8″-16 tin-plated copper studs for maximum conductivity and corrosion resistance
- 7∕ 8″ (22 mm) stud length accepts multiple cable terminals
- Label recesses for circuit identification
- Silver alloy contacts provide high reliability for switching live loads
Specifications
Control Circuit Connection | Tinned Wire |
Nominal Voltage | 24V DC |
Coil Function | Auto-Releasing |
Mounting | #10 |
Amperage Operating Current | 8mA when OFF 13mA when ON |
Amperage Operating Current when changing state | <7A (40ms) |
Terminal Stud Torque | 140 in-lb (15.82 Nm) |
Control Circuit Voltage | 10.1 to 16.5V DC |
Continuous Rating | 500A |
Intermittent Rating | 700A (5 min) |
Cranking Rating 10 sec | 2500A |
Cranking Rating 1 min | 1100A |
Minimum Operating Temperature | -10° C |
Maximum Operating Temperature | 50° C |
Cable Size to Meet Ratings | 2x (4/0) |
Live Current Switching | 300A @ 12V DC |
Master Control Switch Capability | Yes |
Mechanical Endurance | 100,000 Cycles |
Terminal Ring Diameter Clearance | 1.18in (29.97 mm) |
Terminal Stud Length | 0.875in (22.23 mm) |
Terminal Stud Size | 3/8″ – 16 (M10) |
Weight | 0.79 kg |
Note: Specifications subject to change without notice.
SKU | BS-7717 |
---|---|
Barcode # | OEBC527538 |
Brand | Blue Sea Systems |
Shipping Weight | 0.8000kg |
