Features

e-Series On Off Battery Switch with AFD

  • Includes AFD (Alternator Field Disconnect)
  • Ignition protected—safe for installation aboard gasoline powered boats
  • Case design allows surface or rear panel mounting

Specifications

e-Series On-Off Battery Switch with AFD
Switch TypeSingle Circuit ON-OFF
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field DisconnectYes
Maximum Voltage48V DC
Terminal Stud Torque140 in-lb (15.82 Nm)
Continuous Rating350A
Intermittent Rating600A (5 min)
Cranking Rating 10 Sec2000A
Cranking Rating 1 min1000A
Battery Inputs1
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm²)
Mounting HolesAccept 1/4″ (M6) Screw
Terminal Stud Size3/8″ – 16 (M12)
Weight0.59 kg

Note: Specifications subject to change without notice.

Specifications

e-Series On-Off Battery Switch with AFD
Switch TypeSingle Circuit ON-OFF
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field DisconnectYes
Maximum Voltage48V DC
Terminal Stud Torque140 in-lb (15.82 Nm)
Continuous Rating350A
Intermittent Rating600A (5 min)
Cranking Rating 10 Sec2000A
Cranking Rating 1 min1000A
Battery Inputs1
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm²)
Mounting HolesAccept 1/4″ (M6) Screw
Terminal Stud Size3/8″ – 16 (M12)
Weight0.59 kg

Note: Specifications subject to change without notice.

SKU BS-9004e
Barcode # OEBC527542
Brand Blue Sea Systems
Shipping Weight 0.6500kg

Blue Sea Systems E-Series On-Off Battery Switch With Afd

SKU: BS-9004e
Sale price
$114.99
RRP $120.00
Earn 1,140 Outback Rewards Points
Sale price
$114.99
DON'T PAY RRP $120.00
PayPal Checkout
4 payments of $28.75

afterpay More info.

Make 4 payments of $28.75 over 8 weeks and get it now!

zipMoney
From $10 / week
Afterpay
4 payments of $28.75

Calculate Shipping

Features

e-Series On Off Battery Switch with AFD

  • Includes AFD (Alternator Field Disconnect)
  • Ignition protected—safe for installation aboard gasoline powered boats
  • Case design allows surface or rear panel mounting

Specifications

e-Series On-Off Battery Switch with AFD
Switch TypeSingle Circuit ON-OFF
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field DisconnectYes
Maximum Voltage48V DC
Terminal Stud Torque140 in-lb (15.82 Nm)
Continuous Rating350A
Intermittent Rating600A (5 min)
Cranking Rating 10 Sec2000A
Cranking Rating 1 min1000A
Battery Inputs1
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm²)
Mounting HolesAccept 1/4″ (M6) Screw
Terminal Stud Size3/8″ – 16 (M12)
Weight0.59 kg

Note: Specifications subject to change without notice.

Specifications

e-Series On-Off Battery Switch with AFD
Switch TypeSingle Circuit ON-OFF
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field DisconnectYes
Maximum Voltage48V DC
Terminal Stud Torque140 in-lb (15.82 Nm)
Continuous Rating350A
Intermittent Rating600A (5 min)
Cranking Rating 10 Sec2000A
Cranking Rating 1 min1000A
Battery Inputs1
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm²)
Mounting HolesAccept 1/4″ (M6) Screw
Terminal Stud Size3/8″ – 16 (M12)
Weight0.59 kg

Note: Specifications subject to change without notice.

SKU BS-9004e
Barcode # OEBC527542
Brand Blue Sea Systems
Shipping Weight 0.6500kg
