Description
| Specifications | |
|---|---|
| Maximum Voltage | 300V AC 48V DC |
| Number of Terminal Studs | 4 |
| Terminal Type | 3/8"-16 Stud |
| Terminal Stud Torque | 140 in-lb (15.82 Nm) |
Continuous Rating  |
545A AC 600A DC |
| Base Material | UL 94-V0 Rated, Glass Reinforced Thermoplastics |
| Bus Material | Tin-Plated Copper CDA 110/UNS11000 |
| Screw Terminal Torque | 15 in-lb (1.69 Nm) |
| Stud Torque | 140 in-lb (15.82 Nm) |
| Weight | 1.71lb (0.78 kg) |
| Weight | 1.75lb (0.79 kg) |
Specifications
| SKU | BS-2104 |
|---|---|
| Barcode # | OEBC527468 |
| Brand | Blue Sea Systems |
| Shipping Weight | 0.0400kg |
