Battery indicator panel and indicator eyelet
The battery indicator shows the status of the battery. It is an accessory for the Blue Smart and Blue Power IP65 Chargers. It is suitable for 12V lead acid batteries only (flooded, GEL, AGM).

Easy to use
After using the battery it takes about 30 minutes for the battery to regain its steady state condition and for the panel to show a correct status
indication.
Green light: Battery does not need to be charged. Battery 80%-100%
Orange light: Battery can be charged. Battery 60%-80%
Red light: Battery needs charging. Battery 40%-60%
No light: charge immediately to prevent sulfation. Battery <40%

Specifications:

• Voltage: 6-15V
• Back current drain: 0.9mA
• Maximum Current: 30A
• Length of cable: 0.3m
• Cable diameter: 3.3mm2 [AWG12]
• Size 45x26x50mm
• Battery connection type: M8 Eyelet connectors
• Fuse: 30A ATO fuse
• Weight: 0.17kg
• Protection category: IP65
