5” High-Resolution Camera Kit
A High-Resolution 12/24V monitor kit that offers a clear image and enhanced view when reversing. Its Heavy Duty construction makes it suitable for trucks, machinery and vehicles. The HD5120CK also has the added flexibility of connecting up to 2 cameras.
Specifications:
- Monitor:
- TFT Panel: New Grade A LCD
- LCD Size: 5-Inch (Diagonal)
- Display Format: 16:9
- Resolution: 1024 x 600
- Brightness: < 500 CD/M2
- Viewing Angles: 70° Left/Right/Up/Down
- Video System: Auto PAL/NTSC Select
- Video Connect: 2 x 4-Pin (Male)
- Compatibility: Standard & High-Resolution Camera’s
- Buttons: Touch Sensitive
- Connection Type: Universal Standard 4-Pin Configuration (M)
- Camera Triggers: 2
- Monitor View: Normal/Mirror/Flip/Mirror-Flip Image Select
- Guidelines: Selectable On/Off (Camera 2 Input Only)
- Audio: Camera 2 Input Only
- Main Menu: Brightness/Contrast/Colour/Photosensitive (Dimmer), Language, Default Setting, Volume, RLUD, (Screen Orientation), VCOM (Exposure), Ruler Setting (Guidelines), AccTime, Version
- Operating Temp: -20°C ~ +70°C
- Power Input: 10-32V DC (Negative Ground)
- Dimensions: 132.2mm (W) x 94.3mm (H) x 22.45mm (D) – Excluding Bracket & Visor
- Camera:
- Sensor: 1/3” IMX225LQR-C
- Diagonal Viewing Angle: 140°
- Horizontal Viewing Angle: 120°
- Signal System: PAL
- Effective Pixels: 1280 (H) x 720 (V)
- Resolution: 720P
- Orientation: Mirror Image
- Night Vision: 18 Infrared LED’s
- Illumination: 0.001 Lux With IR On
- Ingress Protection: IP69K
- Integrated Microphone: Yes
- Operating Temp: -20 ~ 70° C
- Power Consumption: 3W, 250mA
- Connection Type: Universal Standard 4-Pin Female
- Power Supply: 12V DC
- Dimensions: 98.3mm (W) x 67.7mm (H) x 68mm (D) – Including Bracket
SKU | HD5120CK |
---|---|
Barcode # | OEBC559967 |
Brand | Axis |
Shipping Weight | 2.0000kg |
