FEATURES |
• Dual heating - Incoloy Electric Element and Heat Exchanger Coil. • Incoloy* Electrical Heating Element is available in 800 and 1200 Watts allowing hot water production when engine heat is not available. • Heat Exchanger Coil features a large surface area designed to generate a large output of hot water. • Insulation uses closed cell expanded polyurethane foam (HFC, CFC, HCFC and HFA free). • Enamelled steel tank is internally coated according to DIN 4753.** • Replaceable Magnesium anode is fitted to all Enamelled Steel units to protect against galvanic corrosion. • External casing is made of pre-painted aluminium, chosen because of its suitability for marine applications • Adjustable safety thermostat. • Pressure relief and non-return valve. • Power cable supplied. • Purpose built from high-quality materials for the marine environment: Enamelled Steel Tank: internally coated according to DIN 4753. External Casing: Pre-Painted Aluminium. Mounting Brackets: AISI 304 Stainless Steel. • CE Certified EN 60335. |
Part No. | 44234 |
Max Pressure | 700 kPa |
Connectors | 1/2 inch |
Dimensions (A x B x C) | 320mm x 885mm x 334mm |
Capacity | 45Ltr |
Element | 1200 (5.4A) |
Volts | 230V |
Note | * Incoloy refers to a range of superalloys designed for excellent corrosion resistance as well as strength at high temperatures. ** DIN 4753 refers to the standard for Water heaters and water heating insulations for drinking and service water. |
Please note European Plug - Required Perfectional install and correct fittings fitted.
SKU | 44234 |
---|---|
Barcode # | 9330420187496 |
Brand | ATI |
Shipping Weight | 15.0000kg |
