SELF EXCITING CENTRE PIN ON REG IS FOR WARNING LAMP IF REQUIRED USE 53-903 FOR 5PV PULLEY
Specifications
Voltage 12V
Amperage Hot: 80A @ (96c) Cold: 100A @ (40c)
Mount Leg ID 24mm
C-C Mounts 138mm
Hole ID Top M8
Hole ID Bottom 10mm
Shaft Size 15mm
Pulley Type SINGLE "A"
Pulley Belt Width 12mm
Pulley Grooves 1
Pulley Diameter 69mm
Regulator Type INTERNAL
Series
Connections Plug #
Terminals B+, L (CENTRE PIN)
Excitation INTERNAL
Ground NEGATIVE
Weight (Kg) 3.5kg
SKU | BKS-80RN |
---|---|
Barcode # | 9356659328295 |
Brand | Jaylec |
Shipping Weight | 9.0000kg |
Shipping Width | 0.250m |
Shipping Height | 0.250m |
Shipping Length | 0.250m |
