Best in Class High output @ low RPM
Magnetic Rotor to increase output at Low RPM
Notes:
SELF EXCITING CENTRE PIN ON REG IS FOR WARNING LAMP IF REQUIRED USE 53-903 FOR 5PV PULLEY

Specifications
Voltage 12V
Amperage Hot: 82A @ (96c) Cold: 100A @ (40c)
Mount Leg ID 24mm
C-C Mounts 138mm
Hole ID Top M8
Hole ID Bottom 10mm
Shaft Size 15mm
Pulley Type SINGLE "A"
Pulley Belt Width 12mm
Pulley Grooves 1
Pulley Diameter 69mm
Regulator Type INTERNAL
Series
Connections Plug #
Terminals B+, L (CENTRE PIN)
Excitation INTERNAL
Ground NEGATIVE
Weight (Kg) 3.5kg
