NO WARNING LIGHT NO PIN CONECTION TO BE USED USE 53-903 FOR 5PV PULLEY
Specifications
Voltage 12V
Amperage 55A Hot (96c) Cold 70a (40c)
Mount Leg ID 58mm
C-C Mounts 161mm
Hole ID Top M8
Hole ID Bottom 10mm
Shaft Size 15mm
Pulley Type SINGLE "A"
Pulley Belt Width 23mm
Pulley Grooves 1
Pulley Diameter 89mm
Regulator Type INTERNAL
Series
Connections Plug # N/A Single Wire
Terminals B+, L
Excitation INTERNAL
Ground NEGATIVE
Weight (Kg) 3.7KG
SKU | BKS-55R1 |
---|---|
Barcode # | 9356659170931 |
Brand | Jaylec |
Shipping Weight | 9.0000kg |
Shipping Width | 0.250m |
Shipping Height | 0.250m |
Shipping Length | 0.250m |
