For Primary Unit Only in a Dual system
Notes:
HIGH OUTPUT REPLACEMENT FOR OE THIS ALTERNATOR IS FITTED WITH OE STATOR, ROTOR, REGULATOR AND RECTIFIER. PLEASE NOTE A BATTERY POSITIVE WIRING UPGRADE IS NEEDED FOR THIS ALTERNATOR

Specifications
Voltage 12V
Amperage 240A
Mount Leg ID 55mm
C-C Mounts 175mm
Hole ID Top 11mm
Hole ID Bottom 13mm, 14mm
Shaft Size 17mm
Pulley Type 8PV, FIXED
Pulley Belt Width
Pulley Grooves 8
Pulley Diameter 69mm
Regulator Type INTERNAL
Series
Connections Plug # EP52
Terminals B+, A, D, I
Excitation EXTERNAL
Ground NEGATIVE
