WIRING MUST BE UPGRADED BEFORE FITTMENT
Notes:
THIS ALTERNATOR IS FITTED WITH OE STATOR, ROTOR, REGULATOR AND RECTIFIER. PLEASE NOTE A BATTERY POSITIVE WIRING UPGRADE IS NEEDED FOR THIS ALTERNATOR.

Specifications
Voltage 12V
Amperage 240A
Mount Leg ID 76mm
C-C Mounts 175mm
Hole ID Top M8
Hole ID Bottom 11mm
Shaft Size 17mm
Pulley Type 6PV, FIXED
Pulley Belt Width
Pulley Grooves 6PV
Pulley Diameter 56mm
Regulator Type INTERNAL
Series
Connections Plug # EP39
Terminals B+, L, S
Excitation EXTERNAL
Ground NEGATIVE
