4 PHASE STATOR FOR HIGHER CHARGING AT LOWER RPM
NSK Bearings
Anti Vibtaion Protection

Specifications
Voltage 12V
Amperage 110A Hot (96c) 126A Cold (40c)
Mount Leg ID 56mm
C-C Mounts 170mm
Hole ID Top M8
Hole ID Bottom 10mm
Shaft Size 17mm
Pulley Type SINGLE "A"
Pulley Belt Width
Pulley Grooves 1
Pulley Diameter 64mm
Regulator Type INTERNAL
Series K1
Connections Plug #
Terminals B+, D+, W
Excitation EXTERNAL
Ground NEGATIVE
Weight (Kg) 6.5kg
