4 Phase Stator Rectifier
NSK Bearings
Anti Vibtaion Protection
Specifications
Voltage 12V
Amperage 110A Hot (96c) 126A Cold (40c)
Mount Leg ID 76mm
C-C Mounts 168mm
Hole ID Top 3/8 UNC
Hole ID Bottom 11mm
Shaft Size 17mm
Pulley Type SINGLE "A"
Pulley Belt Width
Pulley Grooves 1
Pulley Diameter 82mm
Regulator Type INTERNAL
Series K1
Connections Plug #
Terminals B+, D+, W
Excitation EXTERNAL
Ground NEGATIVE
SKU | BKS-110F |
---|---|
Barcode # | 9356659125023 |
Brand | Jaylec |
Shipping Weight | 9.0000kg |
Shipping Width | 0.250m |
Shipping Height | 0.250m |
Shipping Length | 0.250m |
